INDICATORS (E1,E24) REFER TO FIG28 (E-7) FOR E2,E4,E15,E16,E17,E18,E21,E22,E34,E39

INDICATORS (E2,E4,E15,E16,E17,E18,E21,E22,E34,E39) FOR SUZUKI GSX-R 750 1986

TAIL LAMP - LICENSE LAMP

INDICATORS (E2,E4,E15,E16,E17,E18,E21,E22,E34,E39) Suzuki MOTO 750 GSX-R 1986 GSX-R750RG
1
LAMP ASSY, FRONT TURN SIGNAL

35601-06B20-000   3560106B20000

3560106B20000
Not available
1
LAMP ASSY, FRONT TURN SIGNAL

35601-06B40-000   3560106B40000

3560106B40000
Not available
1
LAMP ASSY, FRONT TURN SIGNAL

35601-06B50-000   3560106B50000

3560106B50000
Not available
2
DISCONTINUE<br />LENS
DISCONTINUE
LENS

35612-02181-000   3561202181000

3561202181000
Not available
3
DISCONTINUE<br />GASKET
DISCONTINUE
GASKET

35613-48700-000   3561348700000

3561348700000
Not available
4
DISCONTINUE<br />SCREW (4X38)
DISCONTINUE
SCREW (4X38)

35623-02180-000   3562302180000

3562302180000
Not available
5
SCREW

03211-04308-000  

03211-04306-000
 0321104308000

Unit Price

6
GASKET
GASKET

35627-43010-000   3562743010000

3562743010000

Unit Price

7
BULB(12V60/55W,H4)<br />BULB (12V,21W)
BULB(12V60/55W, H4)
BULB (12V, 21W)

09471-12045-000   0947112045000

0947112045000

Unit Price

8
GROMMET, FRONT RH

35674-27A20-000   3567427A20000

3567427A20000
Not available
8
DISCONTINUE<br />GROMMET, FRONT RH
DISCONTINUE
GROMMET, FRONT RH

35674-27A30-000   3567427A30000

3567427A30000
Not available
9
GROMMET, FRONT LH

35684-27A20-000   3568427A20000

3568427A20000
Not available
9
DISCONTINUE<br />GROMMET, FRONT LH
DISCONTINUE
GROMMET, FRONT LH

35684-27A30-000   3568427A30000

3568427A30000
Not available
10
NUT

08316-26105-000  

08316-2010B-000
 0831626105000

Unit Price

11
LAMP ASSY, REAR TURN SIGNAL

35603-28A20-000   3560328A20000

3560328A20000
Not available
11
LAMP ASSY, REAR TURN SIGNAL

35603-28A40-000   3560328A40000

3560328A40000
Not available
11
LAMP ASSY, REAR TURN SIGNAL

35603-28A50-000   3560328A50000

3560328A50000
Not available
12
LENS

35632-02181-000   3563202181000

3563202181000
Not available
13
DISCONTINUE<br />GASKET
DISCONTINUE
GASKET

35613-48700-000   3561348700000

3561348700000
Not available
14
DISCONTINUE<br />SCREW (4X38)
DISCONTINUE
SCREW (4X38)

35623-02180-000   3562302180000

3562302180000
Not available
15
SCREW

03211-04308-000  

03211-04306-000
 0321104308000

Unit Price

16
GASKET
GASKET

35627-43010-000   3562743010000

3562743010000

Unit Price

17
BULB(12V60/55W,H4)<br />BULB (12V,21W)
BULB(12V60/55W, H4)
BULB (12V, 21W)

09471-12045-000   0947112045000

0947112045000

Unit Price

18
DISCONTINUE<br />SPACER
DISCONTINUE
SPACER

35692-06B00-000  

3569206B00000
Not available
19
DISCONTINUE<br />CUSHION
DISCONTINUE
CUSHION

35695-06B00-000   3569506B00000

3569506B00000
Not available
20
DISCONTINUED

09180-10078-000   0918010078000

0918010078000
Not available
21
NUT

08316-26105-000  

08316-2010B-000
 0831626105000

Unit Price

22
RELAY ASSY, TURNSIGNAL

38610-31310-000  

38610-31X50-000
 3861031310000

Unit Price

23
RELAY, TURN SIGNAL

38610-45091-000   3861045091000

3861045091000
Not available
24
DISCONTINUE<br />WIRE, TURN SIGNAL RELAY EARTH
DISCONTINUE
WIRE, TURN SIGNAL RELAY EARTH

36851-35010-000   3685135010000

3685135010000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
