Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

CRANK BALANCER

CAMSHAFT - VALVES FOR SUZUKI KINGQUAD 750 2011

TIMING

Item numbers
CAMSHAFT - VALVES Suzuki QUAD 750 KINGQUAD 2011 LT-A750XP L1/LT-A750XPZ L1 (P02,P28,P33)
1
2
3
4
5
5
6
6
7
7
7
7
8
8
9
9
10
10
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
1
CAMSHAFT, INTAKE

12710-31G00-000   1271031G00000

1271031G00000

Unit Price

2
CAMSHAFT, EXHAUST

12720-31G00-000   1272031G00000

1272031G00000

Unit Price

3
VALVE, INTAKE

12911-31G00-000   1291131G00000

1291131G00000

Unit Price

4
VALVE, EXHAUST

12912-31G00-000   1291231G00000

1291231G00000

Unit Price

5
SPRING, VALVE

12921-31G00-000   1292131G00000

1292131G00000

Unit Price

6
RETAINER, VALVE SPRING
RETAINER, VALVE SPRING

12931-02F10-000   1293102F10000

1293102F10000

Unit Price

7
COTTER, VALVE
COTTER, VALVE

12932-24400-000   1293224400000

1293224400000

Unit Price

8
SEAT, VALVE SPRING
SEAT, VALVE SPRING

12933-38400-000   1293338400000

1293338400000

Unit Price

9
SEAL, OIL(5.5X11X8.2)
OIL SEAL (5.5X11X8.2)

09289-05015-000   0928905015000

0928905015000

Unit Price

10
TAPPET
TAPPET

12891-02F00-000  

12891-02F10-000
 1289102F00000

Unit Price

11
SHIM,TAPPET(T:2.30)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.30)
SHIM, TAPPET

12892-41C00-230   1289241C00230

1289241C00230

Unit Price

11
SHIM,TAPPET(T:2.35)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.35)
SHIM, TAPPET

12892-41C00-235   1289241C00235

1289241C00235

Unit Price

11
SHIM,TAPPET(T:2.40)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.40)
SHIM, TAPPET

12892-41C00-240   1289241C00240

1289241C00240

Unit Price

11
SHIM,TAPPET(T:2.45)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.45)
SHIM, TAPPET

12892-41C00-245   1289241C00245

1289241C00245

Unit Price

11
SHIM,TAPPET(T:2.50)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.50)
SHIM, TAPPET

12892-41C00-250   1289241C00250

1289241C00250

Unit Price

11
SHIM,TAPPET(T:2.55)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.55)
SHIM, TAPPET

12892-41C00-255   1289241C00255

1289241C00255

Unit Price

11
SHIM,TAPPET(T:2.60)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.60)
SHIM, TAPPET

12892-41C00-260   1289241C00260

1289241C00260

Unit Price

11
SHIM,TAPPET(T:2.65)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.65)
SHIM, TAPPET

12892-41C00-265   1289241C00265

1289241C00265

Unit Price

11
SHIM,TAPPET(T:2.70)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.70)
SHIM, TAPPET

12892-41C00-270   1289241C00270

1289241C00270

Unit Price

11
SHIM,TAPPET(T:2.75)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.75)
SHIM, TAPPET

12892-41C00-275   1289241C00275

1289241C00275

Unit Price

11
SHIM,TAPPET(T:2.80)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.80)
SHIM, TAPPET

12892-41C00-280   1289241C00280

1289241C00280

Unit Price

11
SHIM,TAPPET(T:2.85)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.85)
SHIM, TAPPET

12892-41C00-285   1289241C00285

1289241C00285

Unit Price

11
SHIM,TAPPET(T:2.90)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.90)
SHIM, TAPPET

12892-41C00-290   1289241C00290

1289241C00290

Unit Price

11
SHIM,TAPPET(T:2.95)<br />SHIM, TAPPET
SHIM, TAPPET(T:2.95)
SHIM, TAPPET

12892-41C00-295   1289241C00295

1289241C00295

Unit Price

11
SHIM,TAPPET(T:3.00)<br />SHIM, TAPPET
SHIM, TAPPET(T:3.00)
SHIM, TAPPET

12892-41C00-300   1289241C00300

1289241C00300

Unit Price

11
SHIM,TAPPET(T:3.05)<br />SHIM, TAPPET
SHIM, TAPPET(T:3.05)
SHIM, TAPPET

12892-41C00-305   1289241C00305

1289241C00305

Unit Price

11
SHIM,TAPPET(T:3.1)<br />SHIM, TAPPET
SHIM, TAPPET(T:3.1)
SHIM, TAPPET

12892-41C00-310   1289241C00310

1289241C00310

Unit Price

11
SHIM,TAPPET(T:3.15)<br />SHIM, TAPPET
SHIM, TAPPET(T:3.15)
SHIM, TAPPET

12892-41C00-315   1289241C00315

1289241C00315

Unit Price

11
SHIM,TAPPET(T:3.2)<br />SHIM, TAPPET
SHIM, TAPPET(T:3.2)
SHIM, TAPPET

12892-41C00-320   1289241C00320

1289241C00320

Unit Price

11
SHIM,TAPPET(T:3.25)<br />SHIM, TAPPET
SHIM, TAPPET(T:3.25)
SHIM, TAPPET

12892-41C00-325   1289241C00325

1289241C00325

Unit Price

11
SHIM,TAPPET(T:3.3)<br />SHIM, TAPPET
SHIM, TAPPET(T:3.3)
SHIM, TAPPET

12892-41C00-330   1289241C00330

1289241C00330

Unit Price

11
SHIM,TAPPET(T:3.35)<br />SHIM, TAPPET
SHIM, TAPPET(T:3.35)
SHIM, TAPPET

12892-41C00-335   1289241C00335

1289241C00335

Unit Price

11
SHIM,TAPPET(T:3.4)<br />SHIM, TAPPET
SHIM, TAPPET(T:3.4)
SHIM, TAPPET

12892-41C00-340   1289241C00340

1289241C00340

Unit Price

11
SHIM,TAPPET(T:3.45)<br />SHIM, TAPPET
SHIM, TAPPET(T:3.45)
SHIM, TAPPET

12892-41C00-345   1289241C00345

1289241C00345

Unit Price

11
SHIM,TAPPET(T:3.5)<br />SHIM, TAPPET
SHIM, TAPPET(T:3.5)
SHIM, TAPPET

12892-41C00-350   1289241C00350

1289241C00350

Unit Price

12
SHIM SET, TAPPET
SHIM SET, TAPPET INC.REF.NO.11-4~11-25 (5PCS.EACH) & NO.13

12800-41810-000   1280041810000

1280041810000

Unit Price

13
.CASE, TAPPET SHIM

99000-69471-000   9900069471000

9900069471000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CAMSHAFT - VALVES of your Suzuki of KINGQUAD. Let us know if you have any questions.
