LEG SHIELD (CS50D, CS50DD) FIG. 35 (E-12) : CS50GD

LEG SHIELD (CS50GD) FOR SUZUKI CS 80 1982

FRAME HEAD COVER - FRONT FENDER FIG. 38 (F-4) : CS50GD

LEG SEALD, FRONT (BLUE)

48111-02110-04Y 481110211004Y

Not available

LEG SEALD, FRONT (RED)

48111-02110-07P 481110211007P

Not available

LEG SEALD, FRONT (BLUE)

48111-02110-15B 481110211015B

Not available

LEG SEALD, FRONT (GREEN)

48111-02110-15C 481110211015C

Not available

LEG SEALD, FRONT (WHITE)

48111-02110-189 4811102110189

Not available

LEG SEALD, FRONT (SILVER)

48111-02110-737 4811102110737

Not available

LEG SEALD, REAR

48121-02110-000 4812102110000

Not available

EMBLEM, NO. 2

68162-02130-000 6816202130000

Not available

EMBLEM, NO. 1

68161-02130-000 6816102130000

Not available

MOUL SET, LEG SEALD

48100-02831-000 4810002831000

Not available

PROTECTOR, NO. 1

48135-02100-000 4813502100000

Not available

PROTECTOR, NO. 2

48136-02100-000 4813602100000

Not available

COVER, FRONT

48137-02110-000 4813702110000

Not available

GROMMET

09308-27001-000 0930827001000

Not available

BOLT, REAR

01517-06168-000 0151706168000

Not available

BOLT, FENDER REAR

01107-06168-000 0110706168000

Not available

WASHER(6.5X20X1.6)

09160-06020-000

09160-06066-000

$3,97

Unit Price

MAT, FLOOR

43551-02110-000 4355102110000

Not available

BOX ASSY, FRONT (BLUE)

92100-02101-04Y 921000210104Y

Not available

BOX ASSY, FRONT (RED)

92100-02101-07P 921000210107P

Not available

BOX ASSY, FRONT (BLUE)

92100-02101-15B 921000210115B

Not available

BOX ASSY, FRONT (GREEN)

92100-02101-15C 921000210115C

Not available

BOX ASSY, FRONT (WHITE)

92100-02101-189 9210002101189

Not available

BOX ASSY, FRONT (SILVER)

92100-02101-737 9210002101737

Not available

LOCK ASSY

92130-02110-000 9213002110000

Not available

PLATE

92116-02100-000 9211602100000

Not available

CUSHION, LICENCE PLAT

09321-06013-000

09321-06036-000

$3,97

Unit Price

MOUL

92114-02100-000 9211402100000

Not available

RUBBER, NO. 1

92117-02100-000 9211702100000

Not available

RUBBER, NO. 2

92118-02100-000 9211802100000

Not available

6 X 20 CROSS SCREW
SCREW, UPPER

02142-06207-000 0214206207000

$2,97

Unit Price

6X16CROSS SCREW
SCREW, LOWER

02142-06167-000 0214206167000

$2,97

Unit Price

WASHER(6.5X18X1.6)

09160-06007-000

09160-06084-000

$2,97

Unit Price

LOCK WASHER

08321-21068-000 0832121068000

Not available

NUT FIG.42 (H-4) : E16, E18, E22,

08310-11068-000 0831011068000

Not available

SCREW(6X20)
SCREW, SIDE

09125-06025-000 0912506025000

$4,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the LEG SHIELD (CS50GD) of your Suzuki of CS. Let us know if you have any questions.
