FUEL TANK

SEAT (E2, E17, E22) FOR SUZUKI CS 80 1983

CARRIER

SEAT ASSY (BLACK)

45100-07970-50C 451000797050C

Not available

MOLD, SEAT FRONT RH

45191-07910-000 4519107910000

Not available

MOLD, SEAT FRONT LH

45192-07910-000 4519207910000

Not available

MOLD, SEAT REAR RH

45193-07950-000 4519307950000

Not available

MOLD, SEAT REAR LH

45194-07950-000 4519407950000

Not available

RIVET

45194-02150-000 4519402150000

Not available

NUT

09148-03004-000

09148-03011-000

$3,97

Unit Price

SEAT CUSHION
CUSHION, SEAT

09321-08009-000 0932108009000

$4,97

Unit Price

CUSHION, CENTER

09321-14003-000 0932114003000

Not available

CUSHION
CUSHION, REAR

09329-10001-000 0932910001000

$3,97

Unit Price

BRACKET, FRONT UPPER

45210-02400-000 4521002400000

Not available

BRACKET, FRONT LOWER

45285-02100-000 4528502100000

Not available

BOLT, FRONT

09111-06001-000 0911106001000

Not available

NUT, CENTER

08316-16068-000 0831616068000

Not available

NUT, UPPER

09159-06027-000 0915906027000

Not available

SPRING, RH

45247-02150-000 4524702150000

Not available

SPRING, LH

45248-02150-000 4524802150000

Not available

COVER, FRAME UPPER

47181-07900-000 4718107900000

Not available

CUSHION, BATTERY STOP

45255-02100-000 4525502100000

Not available

STRIKER, SEAT LOCK

45210-02150-000 4521002150000

Not available

SHIM

45217-44100-000 4521744100000

Not available

WASHER

08322-21068-000 0832221068000

Not available

NUT, CENTER

08316-16068-000 0831616068000

Not available

PLATE, CLAMP GUIDE

45220-02150-000 4522002150000

Not available

BOLT (5*10)

01104-05108-000 0110405108000

Not available

WASHER, LOCK

08321-21058-000

08321-0105A-000

$2,97

Unit Price

LOCK SET, SEAT

45700-02150-KEY 4570002150KEY

Not available

SCREW

02112-05128-000

02112-05127-000

$3,97

Unit Price

WASHER, LOCK

08321-21058-000

08321-0105A-000

$2,97

Unit Price

TOOL ASSY

09800-03800-000

09800-03801-000

$43,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SEAT (E2, E17, E22) of your Suzuki of CS. Let us know if you have any questions.
