TJRN SIGNAL LAMP (MODELE R)

TAIL LIGHT (MODELE M / N / P / R / S) FOR SUZUKI DR 800 1994

WIRING HARNESS (MODELE M / N / P / R)

Item numbers

LAMP ASSY, REAR COMBINATION

35710-31D00-000 3571031D00000

Not available

.LENS

35712-31D00-000 3571231D00000

Not available

.GASKET

35713-31D00-000 3571331D00000

$19,97

Unit Price

SCREW
.TAPPING SCREW

03211-04207-000 0321104207000

$2,97

Unit Price

.GASKET

35627-43010-000 3562743010000

$3,97

Unit Price

BULB(12V1.4W G30)
.BULB (12V, 21/5W)

09471-12083-000 0947112083000

$9,97

Unit Price

CUSHION

09320-08048-000

09320-08501-000

$5,97

Unit Price

SPACER, 6.1X8X9.5

09180-06044-000

09180-06248-000

$3,97

Unit Price

CHAIN CASE RR WASHER
LOCK WASHER

09160-06056-000 0916006056000

$2,97

Unit Price

NUT 6MM

08316-10063-000

08319-31067-000

$3,97

Unit Price

LAMP ASSY, LICENSE

35910-31D00-000 3591031D00000

Not available

LAMP ASSY, LICENSE

35910-31D10-000 3591031D10000

Not available

.COVER, LENS

35917-30B00-000 3591730B00000

Not available

.LENS

35912-38A20-000 3591238A20000

Not available

GASKET, LICENSE LAMP
.GASKET

35913-38A30-000 3591338A30000

$4,97

Unit Price

BULB(12V10W)
.BULB

09471-12140-000

Not available

.CUSHION

35761-38A31-000 3576138A31000

Not available

DISCONTINUE
.SPACER

35766-38A30-000 3576638A30000

Not available

NUT

09140-04006-000 0914004006000

$7,97

Unit Price

BRACKET, LICENSE PLATE

35927-00A10-000 3592700A10000

$16,97

Unit Price

01550-0616A
BOLT

01550-06163-000

Not available

WASHER 6.5X20X1.6
WASHER

09160-06088-000 0916006088000

$2,97

Unit Price

08310-0006A
NUT

08310-00063-000

Not available

REFLEX REFLECTOR, REAR

35970-12D00-000 3597012D00000

Not available

NUT

08316-26058-000 0831626058000

Not available

SPACER, REAR REFLECTOR

35977-12D00-000 3597712D00000

Not available

WASHER, REAR REFLECTOR

35997-12D00-000 3599712D00000

Not available

REFLEX REFLECTOR
REFLEX REFLECTOR, REAR SIDE

35950-14A20-000 3595014A20000

$18,97

Unit Price

NUT

08316-26058-000 0831626058000

Not available

CUSHION, LICENSE

09321-06028-000 0932106028000

Not available

CAP, OD:40

09250-30010-000

Not available

EMBLEM, REAR FENDER

35995-45110-000 3599545110000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TAIL LIGHT (MODELE M/N/P/R/S) of your Suzuki DR 800 S of DR. Let us know if you have any questions.
