SPEEDOMETER (MODEL M / N / P / R) FOR SUZUKI DR 800 1996

SPEEDOMETER (MODEL S / T)

Item numbers

SPEEDOMETER (KILO)

34110-31D00-000 3411031D00000

Not available

SPEEDOMETER (MILE/KILO)

34110-31D10-000 3411031D10000

Not available

KNOB, TRIP
KNOB

34124-49400-000 3412449400000

$7,97

Unit Price

TACHOMETER

34210-31D00-000 3421031D00000

Not available

PANEL, METER

34950-31D00-000 3495031D00000

Not available

BRACKET, SPEEDOMETER

34111-31D00-000 3411131D00000

Not available

BRACKET, TACHOMETER

34211-31D00-000 3421131D00000

Not available

DAMPER

34196-32C00-000 3419632C00000

Not available

DISCONTINUE
GEAR BOX, SPEEDOMETER

34131-48B10-000 3413148B10000

Not available

DISCONTINUE
GASKET

34132-17C00-000 3413217C00000

Not available

SCREW

02112-34123-000

02112-3412B-000

$3,97

Unit Price

NUT

08310-11045-000

08310-00043-000

$2,97

Unit Price

SOCKET

34170-31D00-000 3417031D00000

Not available

BULB(12V3.4W G30)

09471-12103-000

09471-12085-000

$6,97

Unit Price

BOLT

34199-31D00-000 3419931D00000

Not available

BOLT, 6X20, W/PL WASHE

09116-06143-000

09116-06115-000

$2,97

Unit Price

SPACER, FR (6.4X9X10.5)

09180-06090-000 0918006090000

Not available

SPACER, 6.1X8X9.5

09180-06044-000

09180-06248-000

$3,97

Unit Price

CUSHION

09320-08047-000

09320-08518-000

$5,97

Unit Price

09320-09062

09320-09026-000

Not available

CUSHION, METER

34191-31D00-000 3419131D00000

Not available

BOX ASSY, PILOT LAMP

36380-31D00-000 3638031D00000

Not available

BOX ASSY, PILOT LAMP

36380-31D10-000 3638031D10000

Not available

BRACKET

36383-31D00-000 3638331D00000

Not available

DISCONTINUE
SCREW

03211-04103-000

Not available

SOCKET, PILOT BOX

36394-31D00-000 3639431D00000

Not available

BULB(12V27/8W)
BULB (12V, 2W)

09471-12118-000

Not available

SCREW

02112-04063-000

02112-0406B-000

$2,97

Unit Price

SCREW

02112-34063-000

02112-3406A-000

$3,97

Unit Price

WASHER, LOCK

08321-21045-000

08321-01043-000

$2,97

Unit Price

CABLE ASSY, SPEEDOMETER

34910-31D00-000 3491031D00000

Not available

SCREW

02112-05163-000

02112-0516B-000

$2,97

Unit Price

GUIDE, METER CABLE NO.2
GUIDE, METER CABLE NO.1

34938-14D30-000 3493814D30000

$15,97

Unit Price

BOLT

01550-06207-000 0155006207000

$3,97

Unit Price

WASHER (6.5X20X1.6)

09160-06066-000 0916006066000

$3,97

Unit Price

NUT 6MM

08316-10063-000

08319-31067-000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SPEEDOMETER (MODEL M/N/P/R) of your Suzuki DR 800 S of DR. Let us know if you have any questions.
