Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

SPEEDOMETER (VL800K9 / CK9) REFER TO FIG.29D(F-13) FOR VL800TK9

SPEEDOMETER (VL800TK9) FOR SUZUKI INTRUDER 800 2009

HEADLIGHT

Item numbers
SPEEDOMETER (VL800TK9) Suzuki MOTO 800 INTRUDER 2009 VL800K9(E3/E28)
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
1
CASE, UPR
CASE ASSY

34151-43H00-000   3415143H00000

3415143H00000

Unit Price

2
COVER
CASE, LOWER

34156-43H00-000   3415643H00000

3415643H00000

Unit Price

3
RING

34193-43H00-000   3419343H00000

3419343H00000

Unit Price

4
PLATE, SPEEDOMETER
PLATE, WINDOW

34125-43H00-000   3412543H00000

3412543H00000

Unit Price

5
PACKING
PACKING, RUBBER

34153-43H00-000   3415343H00000

3415343H00000

Unit Price

6
SPEEDOMETER
SPEEDOMETER (MILE/KILO)

34120-43H30-000   3412043H30000

3412043H30000

Unit Price

6
DISCONTINUE
SPEEDOMETER (KILO)

34120-43H20-000   3412043H20000

3412043H20000
Not available
7
KNOB, SPEEDOMETER
NOB

34124-16G00-000   3412416G00000

3412416G00000

Unit Price

8
COVER, SPEEDOMETER
BUSHING

34126-44G00-000   3412644G00000

3412644G00000

Unit Price

9
SEAL
CUSHION, METER

34167-13E00-000   3416713E00000

3416713E00000

Unit Price

10
CUSHION, METER
CUSHION, METER

34996-43410-000   3499643410000

3499643410000

Unit Price

11
SCREW (3X12)

34183-29F00-000   3418329F00000

3418329F00000

Unit Price

12
WASHER(5.5X16X1.2)<br />WASHER, SPEEDOMETER
WASHER(5.5X16X1.2)
WASHER, SPEEDOMETER

09160-05037-000   0916005037000

0916005037000

Unit Price

13
SCREW<br />SCREW, SPEEDOMETER
SCREW
SCREW, SPEEDOMETER

03541-0516A-000   035410516A000

035410516A000

Unit Price

14
RESISTOR ASSY

36510-39F00-000  

36510-39F01-000
 3651039F00000

Unit Price

15
SPACER (6.5X10X11.6)

09180-06319-000   0918006319000

0918006319000

Unit Price

16
CUSHION
CUSHION

09320-10015-000   0932010015000

0932010015000

Unit Price

17
BOLT

09116-06047-000  

01500-06257-000
 0911606047000

Unit Price

18
GUIDE, SPEED SENSOR LEAD
GUIDE, SPEED SENSOR

34938-41F50-000   3493841F50000

3493841F50000

Unit Price

19
SENSOR, SPEED
SENSOR, SPEEDO

34990-41F10-000   3499041F10000

3499041F10000

Unit Price

20
SEAL
SEAL

09286-44001-000   0928644001000

0928644001000

Unit Price

21
MAGNET

34983-27G00-000   3498327G00000

3498327G00000

Unit Price

22
CLAMP<br />CLAMP (L:145)
CLAMP
CLAMP (L:145)

09407-14407-000   0940714407000

0940714407000

Unit Price

23
CLAMP
CLIP, SENSOR LEAD

09403-06410-000   0940306410000

0940306410000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
