Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

ELECTRICAL (MODEL K6 / K7 / K8) REFER TO FIG.28A(F- 6) FOR 1 PLUG, MODEL K9/L0

ELECTRICAL (MODEL K9 / L0 E3 / E28) FOR SUZUKI INTRUDER 800 2010

ELECTRICAL (MODEL K9 / L0 E33)

Item numbers
ELECTRICAL (MODEL K9/L0 E3/E28) Suzuki MOTO 800 INTRUDER 2010 VL800CL0(E3/E28)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1
RELAY ASSY,STARTING MOTOR
RELAY ASSY, STARTING MOTOR

31800-21E20-000  

31800-21E30-000
 3180021E20000

Unit Price

2
COVER<br />COVER, RELAY ASSY
COVER
COVER, RELAY ASSY

31861-47E00-000   3186147E00000

3186147E00000

Unit Price

3
FUSE (30A)
FUSE (30A)

09481-30101-000   0948130101000

0948130101000

Unit Price

4
SCREW(6X8)<br />BOLT (6X8)
SCREW(6X8)
BOLT (6X8)

09128-06013-000   0912806013000

0912806013000

Unit Price

5
RECTIFIER ASSY

32800-41F11-000  

32800-47H00-000
 3280041F11000

Unit Price

6
SCREW

02162-0620B-000  

02162-0620C-000
 021620620B000

Unit Price

7
CLAMP<br />CLAMP (L:90)
CLAMP
CLAMP (L:90)

09407-11402-000   0940711402000

0940711402000

Unit Price

8
COIL ASSY, IGNITION

33410-17G00-000  

33410-17G01-000
 3341017G00000

Unit Price

9
COIL ASSY, IGNITION

33420-41F10-000  

33420-41F11-000
 3342041F10000

Unit Price

10
SPACER (6.4X10X18)

09180-06195-000   0918006195000

0918006195000

Unit Price

11
CLAMP

09403-07308-000   0940307308000

0940307308000

Unit Price

12
BOLT(5X35)
BOLT, IGNITION COIL (5X35)

09106-05033-000   0910605033000

0910605033000

Unit Price

13
CAP, SPARK PLUG

33510-11410-000   3351011410000

3351011410000

Unit Price

14
SEAL, SPARK PLUG
SEAL, SPARK PLUG

33541-47D00-000   3354147D00000

3354147D00000

Unit Price

15
SEAL, HIGH TENSION CORD
SEAL, HIGH TENSION CORD

33542-38B00-000   3354238B00000

3354238B00000

Unit Price

16
CONTROL UNIT, FI

32920-39GB0-000   3292039GB0000

3292039GB0000

Unit Price

17
BRACKET, FI CONTROL UNIT
BRACKET, FI CONT

44880-43H00-000   4488043H00000

4488043H00000

Unit Price

18
SCREW(6X12)
BOLT, FI CONT (6X12)

09139-06108-000   0913906108000

0913906108000

Unit Price

19
SENSOR ASSY, FUEL CUT

33960-06G10-000   3396006G10000

3396006G10000

Unit Price

20
BRACKET, FUEL CUT SENSOR
BRACKET, FUEL CUT

33961-41F00-000   3396141F00000

3396141F00000

Unit Price

21
HOSE
HOSE

09352-50823-600  

09352-50005-600
 0935250823600

Unit Price

22
SPACER, EXH PIPE COVE
SPACER, FUEL CUT

09180-06325-000   0918006325000

0918006325000

Unit Price

23
CUSHION(8X18X5.8)

09320-06017-000  

09320-08516-000
 0932006017000

Unit Price

24
BOLT
BOLT, FUEL CUT

01547-0616A-000   015470616A000

015470616A000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
