Parts catalogue

Parts diagram

SWINGARM

FRONT FORK FOR SUZUKI INTRUDER 800 2014

STEERING COLUMN (VL800L4 E24)

Item numbers
FRONT FORK Suzuki MOTO 800 INTRUDER 2014 VL800 L4/VL800T L4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
1
51103-41F41
DAMPER ASSY, FRONT FORK RH

51103-41F40-000   5110341F40000

5110341F40000
Not available
2
TUBE, OUTER, R
.TUBE, OUTER RH

51131-41F20-000   5113141F20000

5113141F20000

Unit Price

3
.GUIDE, CASE

51469-41F21-000   5146941F21000

5146941F21000

Unit Price

4
.BUSH, GUIDE

51152-11D60-000   5115211D60000

5115211D60000

Unit Price

5
.SPACER, SEAL
.SPACER, SEAL

51168-38B00-000   5116838B00000

5116838B00000

Unit Price

6
.SEAL, OIL
.SEAL, OIL

51153-08D00-000   5115308D00000

5115308D00000

Unit Price

7
CIRCLIP,FORK OIL SEAL<br />.RING
CIRCLIP, FORK OIL SEAL
.RING

51556-38B00-000   5155638B00000

5155638B00000

Unit Price

8
.SEAL, DUST

51571-47D50-000   5157147D50000

5157147D50000

Unit Price

9
.BOLT

51147-06F10-000   5114706F10000

5114706F10000

Unit Price

10
.GASKET
.GASKET

51148-36011-000   5114836011000

5114836011000

Unit Price

11
.PIECE, OIL LOCK

51195-10F00-000   5119510F00000

5119510F00000

Unit Price

12
.SEAT, PIPE

51146-10F00-000   5114610F00000

5114610F00000

Unit Price

13
.SPRING, REBOUND

51177-10F00-000   5117710F00000

5117710F00000

Unit Price

14
RING, PISTON
.RING

51196-47D00-000   5119647D00000

5119647D00000

Unit Price

15
.TUBE, INNER

51110-41F40-000   5111041F40000

5111041F40000

Unit Price

16
.BUSH, SLIDE

51121-42E00-000   5112142E00000

5112142E00000

Unit Price

17
SPRING, FR
.SPRING, FRONT

51171-41F40-000   5117141F40000

5117141F40000

Unit Price

18
.BOLT, FORK

51189-47D50-000   5118947D50000

5118947D50000

Unit Price

19
.O RING
.O RING

51117-12C00-000   5111712C00000

5111712C00000

Unit Price

20
51104-41F41
DAMPER ASSY, FRONT FORK LH

51104-41F40-000   5110441F40000

5110441F40000
Not available
21
TUBE, OUTER, L
.TUBE, OUTER LH

51141-41F20-000   5114141F20000

5114141F20000

Unit Price

22
.GUIDE, CASE

51469-41F21-000   5146941F21000

5146941F21000

Unit Price

23
.BUSH, GUIDE

51152-11D60-000   5115211D60000

5115211D60000

Unit Price

24
.SPACER, SEAL
.SPACER, SEAL

51168-38B00-000   5116838B00000

5116838B00000

Unit Price

25
.SEAL, OIL
.SEAL, OIL

51153-08D00-000   5115308D00000

5115308D00000

Unit Price

26
CIRCLIP,FORK OIL SEAL<br />.RING
CIRCLIP, FORK OIL SEAL
.RING

51556-38B00-000   5155638B00000

5155638B00000

Unit Price

27
.SEAL, DUST

51571-47D50-000   5157147D50000

5157147D50000

Unit Price

28
.BOLT

51147-06F10-000   5114706F10000

5114706F10000

Unit Price

29
.GASKET
.GASKET

51148-36011-000   5114836011000

5114836011000

Unit Price

30
.PIECE, OIL LOCK

51195-10F00-000   5119510F00000

5119510F00000

Unit Price

31
.SEAT, PIPE

51146-10F00-000   5114610F00000

5114610F00000

Unit Price

32
.SPRING, REBOUND

51177-10F00-000   5117710F00000

5117710F00000

Unit Price

33
RING, PISTON
.RING

51196-47D00-000   5119647D00000

5119647D00000

Unit Price

34
.TUBE, INNER

51110-41F40-000   5111041F40000

5111041F40000

Unit Price

35
.BUSH, SLIDE

51121-42E00-000   5112142E00000

5112142E00000

Unit Price

36
SPRING, FR
.SPRING, FRONT

51171-41F40-000   5117141F40000

5117141F40000

Unit Price

37
.BOLT, FORK

51189-47D50-000   5118947D50000

5118947D50000

Unit Price

38
.O RING
.O RING

51117-12C00-000   5111712C00000

5111712C00000

Unit Price

39
.BOLT
.BOLT

07130-10357-000   0713010357000

0713010357000

Unit Price

40
CAP
CAP (OD:12)

09250-08014-000   0925008014000

0925008014000

Unit Price

41
CASE, UNDER

51464-41F21-000   5146441F21000

5146441F21000

Unit Price

42
SEAT, RUBBER

51468-10F00-000   5146810F00000

5146810F00000

Unit Price

43
WASHER

51467-10F70-000   5146710F70000

5146710F70000

Unit Price

44
SPACER

51465-41F20-000   5146541F20000

5146541F20000

Unit Price

45
BOLT

51466-10F00-000   5146610F00000

5146610F00000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
