WIRING HARNESS (MODEL K5 / K6 / K7 / K8) REFER TO FIG.34A(F-12) FOR MODEL K9

WIRING HARNESS (MODEL K9) FOR SUZUKI MARAUDER 800 2009

SWITCHES (MODEL K5 / K6) REFER TO FIG.35A(G- 3) FOR MODEL K7/K8

Item numbers

HARNESS, WIRING

36610-39GA1-000 3661039GA1000

Not available

FUSE (15A)

09481-15501-000 0948115501000

$3,97

Unit Price

FUSE (10A)

09481-10501-000

Not available

CLAMP

09407-05410-000 0940705410000

$7,97

Unit Price

CLAMP

09407-17403-000 0940717403000

$8,97

Unit Price

DIODE

36611-38A00-000

36611-38A10-000

$19,97

Unit Price

BOOT

36717-41F00-000 3671741F00000

$12,97

Unit Price

TAPE, HARNESS(28X50X0.13)
TAPE, WIRING HARNESS

36611-16G00-000 3661116G00000

$3,97

Unit Price

PROTECTOR, WIRING HARNESS
TAPE, WIRING HARNESS

36611-41F00-000 3661141F00000

$8,97

Unit Price

COVER, WIRING HARNESS

36618-15D20-000

36618-15D21-000

$17,97

Unit Price

WIRE, IGNITION COIL LEAD

36854-39G00-000

36854-39G01-000

$43,97

Unit Price

WIRE, RR COMB
WIRE, REAR COMB

36858-39G01-000 3685839G01000

$91,97

Unit Price

PROTECTOR, HARNESS(30X50X3)
TAPE, SIRING HARNESS

36920-33C00-000 3692033C00000

$2,97

Unit Price

PROTECTOR, COWL UNDER
PROTECTOR

94474-17H00-000 9447417H00000

$6,97

Unit Price

CLAMP
CLAMP (L:145)

09407-14407-000 0940714407000

$5,97

Unit Price

CLAMP(L:80)

09404-06433-000

09404-06036-000

$3,97

Unit Price

CLAMP
CLAMP (L:135)

09404-06435-000 0940406435000

$5,97

Unit Price

CLAMP, WIRING HARNESS
CLAMP (L:165)

09407-18402-000 0940718402000

$3,97

Unit Price

CLAMP

09407-19401-000

09407-22403-000

$3,97

Unit Price

SCREW

03541-0410B-000 035410410B000

$2,97

Unit Price

LOCK SET

37102-41820-000 3710241820000

Not available

LOCK ASSY, STEERING

37100-41F80-000 3710041F80000

Not available

37101-41893
LOCK SET

37101-41890-000 3710141890000

Not available

LOCK ASSY, STEERING

37100-41F70-000

37100-41F71-000

$258,97

Unit Price

PROTECTOR, IGNITION SWITCH
PROTECTOR, IGNITION

37187-41F10-000 3718741F10000

$20,97

Unit Price

BOLT
SCREW, STEERING LOCK

09139-08016-000 0913908016000

$5,97

Unit Price

SWITCH ASSY, STOP LAMP

37740-24A00-000 3774024A00000

$19,97

Unit Price

SPRING
SPRING, STOP LAMP

09443-06073-000 0944306073000

$6,97

Unit Price

37840-41F02

37840-41F00-000

Not available

BOLT(6X20)
BOLT

09103-06279-000 0910306279000

$4,97

Unit Price

HORN ASSY

38500-41F30-000 3850041F30000

$78,97

Unit Price

BOLT

01550-0816B-000 015500816B000

$4,97

Unit Price

RELAY ASSY
RELAY ASSY, FUEL PUMP

38740-24X50-000 3874024X50000

$43,97

Unit Price

RELAY ASSY
RELAY ASSY, HEAD LAMP

38740-24A00-000 3874024A00000

$60,97

Unit Price

BRACKET, HEADLAMP RELAY
BRACKET, HEAD LAMP

38741-39G00-000 3874139G00000

$8,97

Unit Price

BOLT
BOLT, BRACKET

01550-0612B-000 015500612B000

$3,97

Unit Price

KEY, BLANK

37146-41F10-000 3714641F10000

$56,97

Unit Price

KEY, BLANK(BOULEVARD)
KEY, BLANK "BOULEVARD"

37146-41FA0-000 3714641FA0000

$93,97

Unit Price

KEY, BLANK "INTRUDER"

37146-41FB0-000 3714641FB0000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
