Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

DRIVESHAFT (SEE NOTE) NOTE : VL800CK7/CK8/CK9/CL0/CUEK8/CUEK9/CUEL0

REAR BRAKE FOR SUZUKI VOLUSIA 800 2010

HANDLEBAR

Item numbers
REAR BRAKE Suzuki MOTO 800 VOLUSIA 2010 VL800CUEL0(E2)
1
2
3
4
5
6
6
7
8
9
10
11
12
13
13
13
13
14
14
15
15
16
17
18
19
1
STAND, PROP

42310-41F01-000   4231041F01000

4231041F01000

Unit Price

2
BOLT,10X37.5<br />BOLT
BOLT, 10X37.5
BOLT

09111-10058-000   0911110058000

0911110058000

Unit Price

3
NUT, PROP STAND
NUT

42321-03FK0-000   4232103FK0000

4232103FK0000

Unit Price

4
SPRING<br />SPRING, INNER
SPRING
SPRING, INNER

09443-14066-000   0944314066000

0944314066000

Unit Price

5
SPRING<br />SPRING, OUTER
SPRING
SPRING, OUTER

09443-19012-000   0944319012000

0944319012000

Unit Price

6
PEDAL, BRAKE

43110-41F10-000  

43110-41F11-000
 4311041F10000

Unit Price

7
ARM, BRAKE ROD

43120-41F00-000   4312041F00000

4312041F00000

Unit Price

8
RUBBER, BRAKE PEDAL

43151-10F00-000  

43151-10F01-000
 4315110F00000

Unit Price

9
BOLT<br />BOLT, ARM
BOLT
BOLT, ARM

07120-0625A-000   071200625A000

071200625A000

Unit Price

10
SPRING
SPRING, RETURN

09443-12051-000   0944312051000

0944312051000

Unit Price

11
BOLT<br />BOLT, ADJUSTER
BOLT
BOLT, ADJUSTER

01500-06207-000   0150006207000

0150006207000

Unit Price

12
NUT
NUT

08310-00067-000   0831000067000

0831000067000

Unit Price

13
PIN

09200-06037-000  

09200-06068-000
 0920006037000

Unit Price

14
WASHER
WASHER

08322-0106B-000   083220106B000

083220106B000

Unit Price

15
PIN<br />COTTER PIN
PIN
COTTER PIN

04111-2015A-000   041112015A000

041112015A000

Unit Price

16
ROD, RR BRAKE FR
ROD, FRONT

43130-41F00-000   4313041F00000

4313041F00000

Unit Price

17
LINK, RR BRAKE
LINK, REAR BRAKE

43140-41F00-000   4314041F00000

4314041F00000

Unit Price

18
SHAFT, BRAKE PEDAL
SHAFT, LINK

43142-27C00-000   4314227C00000

4314227C00000

Unit Price

19
RUBBER, BRAKE LINK

43151-41F00-000  

43151-41F01-000
 4315141F00000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
