TAIL LIGHT

TAIL LIGHT (E2, E4, E21) FOR SUZUKI GS 850 1983

TAIL LIGHT (E17)

LAMP, REAR COMBINATION

35710-49023-000 3571049023000

Not available

LENS

35712-49084-000 3571249084000

Not available

DISCONTINUE
GASKET

35713-49030-000 3571349030000

Not available

BULB(12V21/5W)
BULB

09471-12046-000 0947112046000

$16,97

Unit Price

09471-12140
..BULB (12V, 5W)

09471-12059-000

Not available

SCREW

35627-49030-000

03511-04163-000

$2,97

Unit Price

GASKET

35627-43010-000 3562743010000

$3,97

Unit Price

WASHER(6.5X18X1.6)

09160-06007-000

09160-06084-000

$3,97

Unit Price

FRM RH COVER CUSHION
CUSHION

09320-09004-000 0932009004000

$4,97

Unit Price

CUSHION

09320-09003-000 0932009003000

$3,97

Unit Price

WASHER(6.5X22X1.6)

09160-06012-000

09160-06054-000

$2,97

Unit Price

FENDER FRONT SPACER
SPACER (6.1X9X7.5)

09180-06038-000 0918006038000

$2,97

Unit Price

NUT FIG.42 (H-4) : E16, E18, E22,

08310-11068-000 0831011068000

Not available

LOCK WASHER

08321-21068-000 0832121068000

Not available

BRACKET, LICENCE PLATE

35927-49091-000 3592749091000

Not available

BRACKET, TAIL LAMP

35928-49031-000 3592849031000

Not available

BRACKET, TAIL LAMP

35726-45100-000 3572645100000

Not available

CUSHION, BRACKET

35794-49000-000 3579449000000

Not available

BOLT, RETURN

01107-06258-000 0110706258000

Not available

BOLT FIG.48 (G-10) : GSX1100XD/EXD FIG.49 (G-11) : GSX1100ESD

01107-06308-000 0110706308000

Not available

BOLT, FRONT

01107-06128-000 0110706128000

Not available

BOLT, FENDER REAR

01107-06168-000 0110706168000

Not available

SPACER (6.4X9X15.5)

09180-06087-000 0918006087000

Not available

WASHER(6.5X18X1.6)

09160-06007-000

09160-06084-000

$3,97

Unit Price

F FORK COVER WASHER
WASHER

09169-06016-000 0916906016000

$2,97

Unit Price

LOCK WASHER

08321-21068-000 0832121068000

Not available

NUT FIG.42 (H-4) : E16, E18, E22,

08310-11068-000 0831011068000

Not available

6X16CROSS SCREW
SCREW

02142-06167-000 0214206167000

$2,97

Unit Price

NUT FIG.42 (H-4) : E16, E18, E22,

08310-11068-000 0831011068000

Not available

LOCK WASHER

08321-21068-000 0832121068000

Not available

EMBLEM, REAR SIDE

35992-45110-000 3599245110000

Not available

LOCK WASHER

08322-21058-000 0832221058000

Not available

NUT

08310-11058-000

08310-00057-000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TAIL LIGHT (E2, E4, E21) of your Suzuki GS 850 G of GS. Let us know if you have any questions.
