CYLINDER FOR SUZUKI AP 100 1996

CRANKCASE

Item numbers

CYLINDER HEAD

11111-23402-000 1111123402000

Not available

CYLINDER HEAD

11111-23411-000 1111123411000

Not available

GASKET, CYLINDER HEAD

11141-23400-000 1114123400000

Not available

RUBBER PAD

11151-40900-000 1115140900000

Not available

RUBBER PAD

11251-30530-000 1125130530000

Not available

CYLINDER

11210-23402-0F0 11210234020F0

Not available

CYLINDER

11210-23411-0F0 11210234110F0

Not available

GASKET, CYLINDER

11241-23410-000 1124123410000

Not available

PAD, CYLINDER
RUBBER PAD (N9->6)

11251-36500-000 1125136500000

$12,97

Unit Price

RUBBER PAD

11251-30530-000 1125130530000

Not available

STUD BOLT (L:120)

09108-08056-000 0910808056000

Not available

STUD BOLT (L:123)

09108-08112-000 0910808112000

Not available

NUT

08316-10083-000

08316-1008B-000

$3,97

Unit Price

BOLT, STUD

01421-06168-000

01421-0616A-000

$3,97

Unit Price

NUT 6MM

08316-10063-000

08319-31067-000

$3,97

Unit Price

09482-00121
SPARK PLUG (NGK, B8ES)

09482-00091-000 0948200091000

Not available

SPARK PLUG (ND, W24ES)

09482-00092-000 0948200092000

Not available

09482-00139-CDN
SPARK PLUG (NGK, BP7ES)

09482-00139-000 0948200139000

Not available

SPARK PLUG (ND, W22EPU)

09482-00194-000 0948200194000

Not available

VALVE ASSY, REED

13150-23400-000 1315023400000

Not available

SCREW

02112-03083-000

02112-0308A-000

$2,97

Unit Price

GASKET

13156-23411-000 1315623411000

Not available

SCREW

02112-06123-000

02112-3612A-000

$3,97

Unit Price

PIPE, INTAKE

13110-23400-000 1311023400000

Not available

PIPE, INTAKE

13110-23401-000 1311023401000

Not available

CLAMP

09402-36306-000

09402-36303-000

$12,97

Unit Price

SCREW

02112-36163-000

02112-3616B-000

$4,97

Unit Price

GASKET SET

11400-23842-000 1140023842000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
