SEAT FOR SUZUKI KATANA 1000 2020

STARTER MOTOR

Item numbers

SEAT ASSY(BLACK, SILVER, GRAY)

45100-07L00-BWU 4510007L00BWU

Not available

.CUSHION

09321-10011-000 0932110011000

$4,97

Unit Price

.CUSHION

45148-07L00-000 4514807L00000

$9,97

Unit Price

.CUSHION, SEAT MOUNT

45148-23J00-000 4514823J00000

$8,97

Unit Price

.PLATE, SEAT HOOK RH

45116-07L00-000 4511607L00000

$12,97

Unit Price

.PLATE, SEAT HOOK LH

45117-07L00-000 4511707L00000

$12,97

Unit Price

.CUSHION, SEAT LOCK(10X22X6)

45213-13601-000 4521313601000

$4,97

Unit Price

.STRIKER, SEAT LOCK

45215-26F00-000 4521526F00000

$27,97

Unit Price

.BAND, SEAT

45380-07L00-000 4538007L00000

Not available

.WASHER(6.5X20X1.6)

09160-06088-000 0916006088000

$2,97

Unit Price

.NUT

08316-1006A-000 083161006A000

$3,97

Unit Price

BRACKET, SEAT SUPPORT

45220-47H00-000 4522047H00000

$125,97

Unit Price

SCREW

02122-0630A-000 021220630A000

$2,97

Unit Price

CABLE COMP, SEAT LOCK
CABLE, SEAT LOCK

45280-07L00-000 4528007L00000

$13,97

Unit Price

BAND, WIRING HARNESS
CLAMP(L:125)

09407-14403-000 0940714403000

$3,97

Unit Price

LOCK ASSY, SEAT

95700-14F00-000 9570014F00000

Not available

PLATE, SEAT LOCK ASSY

45289-11F00-000 4528911F00000

$9,97

Unit Price

GUIDE, SEAT LOCK CABLE

45288-14F00-000 4528814F00000

$8,97

Unit Price

BRACKET COMP, SEAT
BRACKET, SEAT

45130-07L00-000 4513007L00000

$29,97

Unit Price

BOLT

07120-0612A-000

07120-0612B-000

$5,97

Unit Price

SPANNER, HEXAGON(5)
HEXAGON, SPANNER(5)

96514-17K00-000 9651417K00000

$8,97

Unit Price

O-RING(D:3.5, ID:56.5)

09280-57003-000 0928057003000

$10,97

Unit Price

SPANNER, OPEN(14X17)
OPEN SPANNER(14X17)

09813-00031-000 0981300031000

$13,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SEAT of your Suzuki KATANA 1000 of KATANA. Let us know if you have any questions.
