Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

ANTI POLLUTION SYSTEM

CLUTCH FOR SUZUKI V-STROM 1000 2006

TRANSMISSION (MODEL K2 / K3) REFER TO FIG.23A(E- 6) FOR MODEL K4/K5/K6

Item numbers
CLUTCH Suzuki MOTO 1000 V-STROM 2006 DL1000K6(E2)
1
2
3
4
5
6
6
7
8
8
8
8
8
8
8
8
9
10
11
11
11
11
11
11
11
12
12
13
14
15
16
17
18
19
20
21
22
23
23
24
25
25A
25B
26
27
28
29
30
31
32
33
34
1
GEAR ASSY, PRI DRIVEN
GEAR ASSY, PRIMARY DRIVEN

21200-06811-000   2120006811000

2120006811000

Unit Price

2
WASHER (25X52X2.5)

09160-25074-000   0916025074000

0916025074000

Unit Price

3
BEARING, PRI DRVN GR
BEARING (35X40X39.8)

09263-35013-000   0926335013000

0926335013000

Unit Price

4
HUB, CLUTCH SLEEVE

21410-06G00-000   2141006G00000

2141006G00000

Unit Price

5
BOLT, CLUTCH SPRING
BOLT, SPRING SUPPORT

21412-06G00-000   2141206G00000

2141206G00000

Unit Price

6
SPRING, CLUTCH

21413-06G00-000  

21413-06G10-000
 2141306G00000

Unit Price

7
WASHER
WASHER

21414-29F00-000   2141429F00000

2141429F00000

Unit Price

8
PLATE, CLUTCH DRIVE NO.1

21441-24F20-000  

2144124F20000
Not available
9
PLATE, CLUTCH DRIVE NO.3
PLATE, CLUTCH DRIVE NO.2

21442-24F00-000   2144224F00000

2144224F00000

Unit Price

10
PLATE, CLUTCH DRIVE NO.2
PLATE, CLUTCH DRIVE NO.3

21441-24F10-000   2144124F10000

2144124F10000

Unit Price

11
PLATE, CLUTCH DRIVEN NO.1(T:2.0
PLATE, CLUTCH DRIVEN

21451-24F00-000   2145124F00000

2145124F00000

Unit Price

12
PLATE, CLUTCH DRIVEN NO.4(T:2.3
PLATE, CLUTCH DRIVEN

21451-24F10-000   2145124F10000

2145124F10000

Unit Price

13
DISC, CLUTCH PRESSURE
DISK, CLUTCH PRESSURE

21462-06G00-000   2146206G00000

2146206G00000

Unit Price

14
SEAT, WAVE WASHER

21471-06G00-000   2147106G00000

2147106G00000

Unit Price

15
WASHER, CLUTCH PLATE WAVE

21472-06G00-000   2147206G00000

2147206G00000

Unit Price

16
NUT<br />NUT, CLUTCH SLEEVE HUB
NUT
NUT, CLUTCH SLEEVE HUB

09159-24010-000   0915924010000

0915924010000

Unit Price

17
WASHER SLEEVE HUB<br />WASHER, CLUTCH SLEEVE
WASHER SLEEVE HUB
WASHER, CLUTCH SLEEVE

09160-25056-000   0916025056000

0916025056000

Unit Price

18
WASHER CL SLEEVE HUB<br />WASHER, CLUTCH SLEEVE
WASHER CL SLEEVE HUB
WASHER, CLUTCH SLEEVE

09164-24006-000   0916424006000

0916424006000

Unit Price

19
SHIM,25X38X1.0<br />WASHER, SLEEVE HUB NUT
SHIM, 25X38X1.0
WASHER, SLEEVE HUB NUT

09181-25223-000   0918125223000

0918125223000

Unit Price

20
ROD,CLUTCH<br />ROD, CLUTCH PUSH RH
ROD, CLUTCH
ROD, CLUTCH PUSH RH

23110-27A00-000   2311027A00000

2311027A00000

Unit Price

21
ROD, CLUTCH PUSH LH
ROD, CLUTCH PUSH LH

23111-26D00-000   2311126D00000

2311126D00000

Unit Price

22
PIECE, CLUTCH PUSH
PIECE, CLUTCH PUSH

23121-31E00-000   2312131E00000

2312131E00000

Unit Price

23
23160-06G21
CYLINDER, CLUTCH RELEASE

23160-06G01-000  

2316006G01000
Not available
24
CUP
CUP

23163-06B00-000   2316306B00000

2316306B00000

Unit Price

25
SPRING,CLUTCH CYLINDER<br />SPRING
SPRING, CLUTCH CYLINDER
SPRING

23164-05A00-000   2316405A00000

2316405A00000

Unit Price

25A
COVER, DUST

23166-02F20-000   2316602F20000

2316602F20000

Unit Price

25B
COVER, DUST

23166-06G00-000   2316606G00000

2316606G00000

Unit Price

26
BLEEDER
BLEEDER

59121-01A00-000   5912101A00000

5912101A00000

Unit Price

27
CAP, BLEEDER
CAP, BLEEDER

59122-01A00-000   5912201A00000

5912201A00000

Unit Price

28
PIN
PIN, CLUTCH RELEASE CYLINDER

04221-08149-000   0422108149000

0422108149000

Unit Price

29
BOLT

07130-06653-000  

07130-0665B-000
 0713006653000

Unit Price

30
BOLT

07130-06703-000  

07130-0670B-000
 0713006703000

Unit Price

31
WASHER<br />WASHER, CLUTCH PUSH
WASHER
WASHER, CLUTCH PUSH

09160-15045-000   0916015045000

0916015045000

Unit Price

32
SPACER, CL RLSE CYL
SPACER, CLUTCH RELEASE

23171-06G00-000   2317106G00000

2317106G00000

Unit Price

33
BEARING(15X28X2)<br />BEARING, CLUTCH PUSH
BEARING(15X28X2)
BEARING, CLUTCH PUSH

09263-15003-000   0926315003000

0926315003000

Unit Price

34
SEAL, CLUTCH PUSH ROD
SEAL, CLUTCH PUSH (6X34X10.5)

09283-06008-000   0928306008000

0928306008000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CLUTCH of your Suzuki V-STROM 1000 of V-STROM. Let us know if you have any questions.
