Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

CRANKCASE (2) (DL1050UQ,DL1050WQ)

CRANKCASE (2) FOR SUZUKI V-STROM 1050 2021

CRANKCASE COVER

Item numbers
CRANKCASE (2) (DL1050UC,DL1050WC) Suzuki MOTO 1050 V-STROM 2021 DL1050UC M1
1
1
2
2
3
4
5
6
6
7
7
8
8
9
9
9
9
10
10
10
10
11
12
13
14
15
16
17
18
19
20
21
22
1
JET,OIL<br />JET AIR(#14)
JET, OIL
JET AIR(#14)

09493-28010-000   0949328010000

0949328010000

Unit Price

2
O RING<br />O-RING(D:1.2,ID:4)
O RING
O-RING(D:1.2, ID:4)

09280-04004-000   0928004004000

0928004004000

Unit Price

3
O RING(D:1.9, ID:12.6)

09280-13007-000  

09280-12009-000
 0928013007000

Unit Price

4
JET,OIL GALLERY<br />JET,T/M OIL GALLERY
JET, OIL GALLERY
JET, T/M OIL GALLERY

09493-20014-000   0949320014000

0949320014000

Unit Price

5
O RING<br />O-RING(D:1.2,ID:4)
O RING
O-RING(D:1.2, ID:4)

09280-04004-000   0928004004000

0928004004000

Unit Price

6
BOLT(6X12)
BOLT(6X12)

09106-06075-000   0910606075000

0910606075000

Unit Price

7
O-RING(D:1.2,ID:4.7)
O-RING(D:1.2, ID:4.7)

09280-05007-000   0928005007000

0928005007000

Unit Price

8
JET, PISTON COOLING

11390-06G10-000   1139006G10000

1139006G10000

Unit Price

9
GASKET(8.2X14X1)
GASKET(8.2X14X1)

09168-08016-000   0916808016000

0916808016000

Unit Price

10
BOLT
BOLT

01550-0812A-000  

01550-0812B-000
 015500812A000

Unit Price

11
GASKET OIL GALLERY<br />GASKET(16X22X2)
GASKET OIL GALLERY
GASKET(16X22X2)

09168-16002-000   0916816002000

0916816002000

Unit Price

12
PLUG,OIL<br />PLUG(16X8)
PLUG, OIL
PLUG(16X8)

09248-16012-000   0924816012000

0924816012000

Unit Price

13
GASKET,13.8X18.8X0.4<br />GASKET(13.8X18.8X4.8)
GASKET, 13.8X18.8X0.4
GASKET(13.8X18.8X4.8)

09168-14002-000   0916814002000

0916814002000

Unit Price

14
PLUG, OIL DRAIN
PLUG(14X20)

09247-14036-000   0924714036000

0924714036000

Unit Price

15
BOLT, ENG MTG(L350)
BOLT, ENG MTG

09103-12141-000   0910312141000

0910312141000

Unit Price

16
NUT, ENG MTG
NUT

09159-12081-000   0915912081000

0915912081000

Unit Price

17
BOLT(10X225)
BOLT(10X225)

09103-10205-000   0910310205000

0910310205000

Unit Price

18
BOLT(10X265)<br />BOLT(10X260)
BOLT(10X265)
BOLT(10X260)

09103-10226-000   0910310226000

0910310226000

Unit Price

19
NUT
NUT

08319-3110A-000   083193110A000

083193110A000

Unit Price

20
SWITCH ASSY,OIL PRESSURE
SWITCH ASSY, OIL PRESSURE

37820-33D10-000  

37820-33D11-000
 3782033D10000

Unit Price

21
.BOLT, OIL PRESSURE SWITCH

37822-33D00-000   3782233D00000

3782233D00000

Unit Price

22
CAP, ENG MTG NUT

11611-06L00-000   1161106L00000

1161106L00000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKCASE (2) (DL1050UC,DL1050WC) of your Suzuki V-STROM 1050 of V-STROM. Let us know if you have any questions.

Genuine parts for Suzuki 1050 V-STROM 2021

BODY/FRAME ELECTRICAL ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 1050 V-STROM 2021

Select your Suzuki 2021 model

1050 V-STROM 2021 DL1050UC M1

V-STROM 1050

Suzuki V-STROM

Displacement: 1050 cc
Year: 2021
Model code DL1050UC M1
Color: Pearl Brilliant White - Glass Blaze Orange (B1F) / Champion Yellow No.2 (YU1) / Glass Sparkle Black (YVB) / Metallic Oort Gray (BT1)
