CRANKCASE (MODEL Z) FIG. 6 (B-8) : MODEL D

CRANKCASE (MODEL D) FOR SUZUKI GSX 1100 1982

CRANKCASE COVER (MODEL Z) FIG.8 (B-11) : MODEL D

CRANKCASE SET

11300-49870-000 1130049870000

Not available

09206-13001-000

04211-13189-000

$3,97

Unit Price

BOLT (8*155)

09103-08059-000 0910308059000

Not available

.BOLT (8X125)

09103-08020-000 0910308020000

Not available

.BOLT (8X100)

09103-08009-000 0910308009000

Not available

BOLT

01517-08905-000

01550-0890B-000

$7,97

Unit Price

BOLT

01517-08655-000 0151708655000

Not available

.BOLT (8X60)

01517-08605-000 0151708605000

Not available

.BOLT (8X50)

01517-08505-000 0151708505000

Not available

BOLT (6*85)

01517-06855-000 0151706855000

Not available

.BOLT (6X75)

01517-06755-000 0151706755000

Not available

BOLT

01517-06555-000

01550-06553-000

$4,97

Unit Price

.BOLT (6X40)

01517-06405-000 0151706405000

Not available

DISCONTINUE
STUD BOLT

01421-06358-000

Not available

NUT, CENTER

08316-16068-000 0831616068000

Not available

DISCONTINUE
NOZZLE, OIL GALLERY

09364-05005-000 0936405005000

Not available

RING
O RING

09280-03003-000 0928003003000

$3,97

Unit Price

KICK GEAR O RING
O RING

09280-13001-000 0928013001000

$6,97

Unit Price

BOLT (10*230)

09100-10140-000 0910010140000

Not available

BOLT (10*250)

09100-10142-000 0910010142000

Not available

BOLT(10X165)

09100-10137-000

09100-10078-000

$20,97

Unit Price

BOLT (10X60)

01107-10605-000 0110710605000

Not available

NUT

09159-10011-000 0915910011000

$6,97

Unit Price

ENGINE MOUNT NUT N02
NUT

09159-10020-000 0915910020000

$10,97

Unit Price

WASHER

08322-11105-000 0832211105000

Not available

REAR SPENSION WASHER
WASHER

09160-10005-000 0916010005000

$2,97

Unit Price

LOCK WASHER

08321-21105-000 0832121105000

Not available

SPACER, ENGINE MOUNT(L:65)
SPACER

11610-45410-000 1161045410000

$17,97

Unit Price

RUBBER PAD, CRANKCASE

11252-25000-000 1125225000000

Not available

PLUG

09247-14012-000

09247-14026-000

$6,97

Unit Price

SPARK PLUG GASKET
GASKET

09168-14004-000 0916814004000

$2,97

Unit Price

DISCONTINUE
CAP, OIL GALLERY

11394-45000-000 1139445000000

Not available

DISCONTINUE

11497-45000-000

Not available

.SCREW

02122-06168-000 0212206168000

Not available

HOUSING, SWITCH

16445-49010-000 1644549010000

Not available

O RING, PRESSURE SWITCH HOUSING
O RING

16448-45000-000 1644845000000

$19,97

Unit Price

BOLT (6*25)

01517-06258-000 0151706258000

Not available

GASKET

09168-06009-000 0916806009000

Not available

SWITCH ASSY, OIL PRESSURE

37820-45060-000

37820-45061-000

$46,97

Unit Price

CENT SPACER O RING
O RING

09280-19001-000 0928019001000

$2,97

Unit Price

GAGE, OIL TEMPERATURE

34870-31300-000 3487031300000

Not available

GAGE, OIL TEMPERATURE

34870-49000-000 3487049000000

Not available

PLATE, OIL SEPARATER RH

11521-49200-000 1152149200000

Not available

PLATE, OIL SEPARATER LH

11522-49200-000 1152249200000

Not available

.SCREW

02112-06088-000 0211206088000

Not available

PLUG, ENGINE OIL

09247-14022-000 0924714022000

Not available

SPARK PLUG GASKET
WASHER

09168-14004-000 0916814004000

$2,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKCASE (MODEL D) of your Suzuki 1100 GSX of GSX. Let us know if you have any questions.
