CRANKSHAFT

CARBURETOR FOR SUZUKI AP 115 1998

AIR FILTER

Item numbers

GASKET, FLOAT CAHMBER

13251-23010-000

13251-03410-000

$8,97

Unit Price

FLOAT

13250-04700-000 1325004700000

$35,97

Unit Price

WASHER

13382-03110-000 1338203110000

$4,97

Unit Price

JET, MAIN (97.5)

09491-97003-000 0949197003000

$22,97

Unit Price

JET, NEEDLE (O-8)

09494-00418-000 0949400418000

Not available

JET, NEEDLE (O-9)

09494-00924-000 0949400924000

Not available

NEEDLE, JET (4D01-2)

13383-23400-000 1338323400000

Not available

CLIP
E RING

13394-10010-000 1339410010000

$6,97

Unit Price

THROTTLE VALVE (CA:1.5)

13551-23400-000 1355123400000

Not available

JET, PILOT
JET, PILOT (20)

09492-20008-000 0949220008000

$22,97

Unit Price

GASKET, NEEDLE VALVE
WASHER

13392-01010-000 1339201010000

$3,97

Unit Price

VALVE ASSY, NEEDLE

13370-23010-000 1337023010000

$63,97

Unit Price

VALVE ASSY, NEEDLE

13370-23420-000 1337023420000

Not available

PIN, FLOAT
PIN

13254-01010-000 1325401010000

$5,97

Unit Price

HOSE

09352-30503-600

09352-30504-600

$11,97

Unit Price

SCREW

13601-04148-000 1360104148000

$4,97

Unit Price

PLATE
PLATE, HOSE CLIP

13693-30010-000 1369330010000

$8,97

Unit Price

HOSE(3X5X650)
HOSE, OVER FLOW (3X5X650)

13684-40A00-000 1368440A00000

$13,97

Unit Price

SCREW, THROTTLE STOP

13267-95110-000 1326795110000

$9,97

Unit Price

SPRING, THROTTLE SCREW
SPRING

13268-48700-000 1326848700000

$6,97

Unit Price

SCREW, PILOT AIR
PILOT AIR SCREW

13269-95110-000 1326995110000

$17,97

Unit Price

SPRING

13268-01010-000 1326801010000

$7,97

Unit Price

SPRING, THROTTLE VALVE
SPRING, THROTTLE VALVE RETURN

13573-36110-000 1357336110000

$6,97

Unit Price

STOPPER, NEEDLE CLIP
PLATE

13581-09210-000 1358109210000

$9,97

Unit Price

PLUG, DRAIN
SCREW, DRAIN

13247-02340-000 1324702340000

$8,97

Unit Price

PLUNGER, STARTER
VALVE, STARTER

13411-01010-000 1341101010000

$23,97

Unit Price

CAP, STARTER

13418-03110-000 1341803110000

Not available

NUT

13661-16600-000 1366116600000

$9,97

Unit Price

ADJUSTER, CABLE

13577-22600-000 1357722600000

$11,97

Unit Price

CAP, CABLE ADJUSTER
CAP

13681-33010-000 1368133010000

$15,97

Unit Price

SPRING
SPRING, STARTER

13417-01010-000 1341701010000

$6,97

Unit Price

09355-25001-600
HOSE (2.5X7X600)

09355-25705-600

Not available

HOSE(3.5X7.5X600)

09355-35755-600

09355-35007-600

$16,97

Unit Price

99x

CARBURETOR ASSY

13200-23490-000 1320023490000

Not available

99x

CARBURETOR ASSY

13200-23491-000 1320023491000

Not available

99x

CARBURETOR ASSY

13200-234B0-000 13200234B0000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
