Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

FUEL TANK (MODEL K7) REFER TO FIG.40D(G-13) FOR MODEL K7 FOR CZZ

FUEL TANK (MODEL K7 FOR CZZ) FOR SUZUKI HAYABUSA 1300 2007

FAIRING (MODEL K4) COLOR : NY2=YD8(SILVER),YBA(BLUE)

TANK ASSY, FUEL (WHITE)

49100-24F50-YC3 4910024F50YC3

Not available

TAPE SET

68110-24F50-DEU 6811024F50DEU

Not available

TAPE SET, LOWER

68110-24F60-DEU 6811024F60DEU

Not available

EMBLEM, S
EMBLEM

68111-18G20-000 6811118G20000

$32,97

Unit Price

DISCONTINUE
CAP SET, FUEL TANK

44201-33810-000

Not available

BOLT, L:20
BOLT

09106-05017-000 0910605017000

$4,97

Unit Price

DISCONTINUE
SHIELD, HEAT

44191-24F10-000 4419124F10000

Not available

SCREW
BOLT, FRONT

09139-06029-000 0913906029000

$9,97

Unit Price

CLUTCH REL WASHER

09160-06036-000

09160-06019-000

$2,97

Unit Price

RR COMB LAMP CUSHION
CUSHION

09320-09009-000 0932009009000

$7,97

Unit Price

WASHER
SPACER

09169-06062-000 0916906062000

$4,97

Unit Price

COVER, FUEL TANK SIDE, R
COVER, SIDE RH

44533-24F00-000 4453324F00000

$27,97

Unit Price

COVER, FUEL TANK SIDE, L
COVER, SIDE LH

44543-24F00-000 4454324F00000

$27,97

Unit Price

PLATE, FUEL TANK SIDE
PLATE, SIDE

44540-24F10-000 4454024F10000

$16,97

Unit Price

SCREW

02142-0610B-000 021420610B000

$2,97

Unit Price

DISCONTINUE
BRACKET, TANK

44560-24F01-000 4456024F01000

Not available

BOLT

09116-06152-000 0911606152000

$3,97

Unit Price

09320-08527
CUSHION

09320-08001-000 0932008001000

Not available

WASHER
SPACER

09169-06062-000 0916906062000

$4,97

Unit Price

CUSHION, FUEL TANK SIDE

44541-24F00-000

44541-24F01-000

$14,97

Unit Price

DISCONTINUE
SPACER

44561-33E10-000 4456133E10000

Not available

BOLT

01550-0895B-000 015500895B000

$7,97

Unit Price

STAY, FUEL TANK
STAY

44574-33E01-000 4457433E01000

$33,97

Unit Price

CLAMP
CLIP

09403-05310-000 0940305310000

$5,97

Unit Price

DISCONTINUE
BRACKET, REAR

44550-24F00-000 4455024F00000

Not available

BOLT
BOLT, LOWER

01550-0812B-000 015500812B000

$4,97

Unit Price

HOSE, FUEL TANK BREATHER

44423-24F00-000

44423-24F01-000

$19,97

Unit Price

HOSE, (7X11X600)

09352-70113-600

09352-70119-600

$19,97

Unit Price

CLAMP(L:65)

09404-06431-000

09404-06207-000

$3,97

Unit Price

CUSHION(20X20X1)
CUSHION, FRONT

44534-24F00-000 4453424F00000

$5,97

Unit Price

CUSHION(20X20X1)

44535-24F00-000

44534-24F00-000

$5,97

Unit Price

DISCONTINUE
SHEET, HEAT SHIELD RUBBER

44271-24F00-000 4427124F00000

Not available

CLAMP, WIRING HARNESS
CLAMP

09407-18402-000 0940718402000

$3,97

Unit Price

CLIP
CLIP (BLACK)

09409-06322-5PK 09409063225PK

$4,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FUEL TANK (MODEL K7 FOR CZZ) of your Suzuki HAYABUSA 1300 of HAYABUSA. Let us know if you have any questions.
