Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

CAMSHAFT - VALVES

TIMING FOR SUZUKI BOULEVARD-M91 1500 2010

THROTTLE BODY

Item numbers
TIMING Suzuki MOTO 1500 BOULEVARD-M91 2010 VZ1500L0(E2)
1
1
2
2
3
3
4
4
4
4
5
6
7
8
9
9
10
10
11
11
12
12
1
CHAIN, CAMSHAFT DRIVE

12760-40H00-000   1276040H00000

1276040H00000

Unit Price

2
GUIDE, CAM CHAIN

12771-40H00-000  

12771-40H01-000
 1277140H00000

Unit Price

3
TENSIONER, CAM CHAIN

12811-40H00-000  

12811-40H01-000
 1281140H00000

Unit Price

4
BOLT, CAM CHAIN TENSIONER
BOLT

12812-31G00-000  

1281231G00000
Not available
5
ADJUSTER ASSY, TENSIONER FR

12830-40H00-000   1283040H00000

1283040H00000

Unit Price

6
GASKET, TENSIONER ADJUSTER
GASKET

12837-24F10-000   1283724F10000

1283724F10000

Unit Price

7
ADJUSTER ASSY, TENSIONER RR

12830-40H10-000   1283040H10000

1283040H10000

Unit Price

8
GASKET, TENSIONER ADJUSTER
GASKET

12837-24F10-000   1283724F10000

1283724F10000

Unit Price

9
SPRING

12831-41G00-000   1283141G00000

1283141G00000

Unit Price

10
PLUG, TENSIONER ADJUSTER
PLUG

12833-17G00-000   1283317G00000

1283317G00000

Unit Price

11
GASKET, TENSIONER ADJUSTER
GASKET

12837-27G00-000   1283727G00000

1283727G00000

Unit Price

12
BOLT
BOLT

07130-0625B-000   071300625B000

071300625B000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TIMING of your Suzuki of BOULEVARD-M91. Let us know if you have any questions.

Genuine parts for Suzuki 1500 BOULEVARD-M91 2010

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 1500 BOULEVARD-M91 2010

Select your Suzuki 2010 model

1500 BOULEVARD-M91 2010 VZ1500L0(E2)

Suzuki BOULEVARD-M91

Displacement: 1500 cc
Year: 2010
Model code VZ1500L0(E2)
