REAR FAIRING (MODEL K4) COLOR : AAV = YC3(WHITE), YV2(SILVER)

FAIRING (MODEL W / X) FOR SUZUKI INTRUDER 1500 2004

FAIRING (MODEL Y / K1) COLOR : K7E = 14L(WHITE), Y4L(YELLOW)

Item numbers
FAIRING (MODEL W/X) Suzuki MOTO 1500 INTRUDER 2004 VL1500K4(E2)
1
1
1
1
2
2
2
2
3
4
4A
5
6
7
8
9
9A
10
11
11
12
13
14
15
16
17
18
1
DISCONTINUE
COVER, FRAME RH (BLACK)

47110-10F00-019   4711010F00019

4711010F00019
Not available
1
47110-10F00-13L

47110-10F00-33J  

4711010F0033J
Not available
1
DISCONTINUE
COVER, FRAME RH (YELLOW)

47110-10F00-Y4L   4711010F00Y4L

4711010F00Y4L
Not available
1
COVER, FRAME RH (BLACK)

47110-10F00-Y7L   4711010F00Y7L

4711010F00Y7L
Not available
2
COVER, FRAME, L NON-PAINTED

47210-10F00-Y7L  

47210-10F00-13L
 4721010F00Y7L

Unit Price

2
DISCONTINUE
COVER, FRAME LH (BLACK)

47210-10F00-019   4721010F00019

4721010F00019
Not available
2
DISCONTINUE
COVER, FRAME LH (BLACK)

47210-10F00-33J   4721010F0033J

4721010F0033J
Not available
2
DISCONTINUE
COVER, FRAME LH (YELLOW)

47210-10F00-Y4L   4721010F00Y4L

4721010F00Y4L
Not available
3
CUSHION, FRAME COVER
CUSHION

47117-45000-000   4711745000000

4711745000000

Unit Price

4
SCREW
SCREW

09139-06030-000   0913906030000

0913906030000

Unit Price

4A
WASHER 6.5X15X1<br />WASHER
WASHER 6.5X15X1
WASHER

09160-06094-000   0916006094000

0916006094000

Unit Price

5
SHIELD, FRAME COVER, R
SHIELD, FRAME COVER RH

47166-10F00-000   4716610F00000

4716610F00000

Unit Price

6
DISCONTINUE
BODY, TOOL HOLDER

47431-10F00-000   4743110F00000

4743110F00000
Not available
7
CAP, TOOL HOLDER

47432-10F00-000   4743210F00000

4743210F00000

Unit Price

8
DISCONTINUE
SHIELD, BODY

47436-10F00-000   4743610F00000

4743610F00000
Not available
9
BOLT
BOLT

09111-06066-000   0911106066000

0911106066000

Unit Price

9A
MOLDING, FRAME COVER, L
MOLDING, LH

47212-10F00-000   4721210F00000

4721210F00000

Unit Price

10
COVER, TOOL HOLDER

47440-10F00-000   4744010F00000

4744010F00000

Unit Price

11
CUSHION
CUSHION

09320-08047-000  

09320-08518-000
 0932008047000

Unit Price

12
LOCK SET, COVER

95700-07860-000  

95700-07861-000
 9570007860000

Unit Price

13
09800-21073
TOOL ASSY

09800-21016-000  

0980021016000
Not available
14
HEXAGON SPANNER, 12

09816-00139-000   0981600139000

0981600139000
Not available
15
SPANNER, HEXAGON(4)
HEXAGON SPANNER, 4

09816-00103-000   0981600103000

0981600103000

Unit Price

16
SPANNER, 8X10

09813-00027-000   0981300027000

0981300027000
Not available
17
HEXAGON SPANNER, 5

09816-00059-000   0981600059000

0981600059000

Unit Price

18
BATTERY BAND
BAND, TOOL

09462-00067-000   0946200067000

0946200067000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
