TAIL LIGHT

WIRING HARNESS FOR SUZUKI INTRUDER 1500 2009

SWITCHES (MODEL K5 / K6) REFER TO FIG.34A(G- 7) FOR MODEL K7/K8/K9

Item numbers

HARNESS, WIRING

36610-10FC0-000 3661010FC0000

Not available

HARNESS, WIRING

36610-10FG0-000 3661010FG0000

Not available

FUSE (10A)

09481-10501-000

Not available

FUSE (15A)

09481-15501-000 0948115501000

$3,97

Unit Price

COVER, SPEEDOMETER COUPLER
COVER, SPEEDOMETER

36618-33E00-000 3661833E00000

$7,97

Unit Price

CLAMP(L:65)

09404-06429-000

09404-06039-000

$3,97

Unit Price

CLAMP(L:80)

09404-06433-000

09404-06036-000

$3,97

Unit Price

CLAMP
CLAMP (L:135)

09404-06435-000 0940406435000

$5,97

Unit Price

CLAMP
CLAMP (L:90)

09407-11402-000 0940711402000

$3,97

Unit Price

BAND, WIRING HARNESS
CLAMP (L:125)

09407-14403-000 0940714403000

$3,97

Unit Price

CLAMP, WIRING HARNESS
CLAMP (L:165)

09407-18402-000 0940718402000

$3,97

Unit Price

CLAMP
CLAMP (L:235)

09407-25401-000 0940725401000

$8,97

Unit Price

CLAMP

09407-19401-000

09407-22403-000

$3,97

Unit Price

CLAMP
CLAMP (L:145)

09407-14407-000 0940714407000

$5,97

Unit Price

WIRE, HORN LEAD

36854-10F00-000 3685410F00000

Not available

DISCONTINUE
WIRE, HORN LEAD

36852-21E10-000 3685221E10000

Not available

DISCONTINUE
BRACKET, FUSE

36744-10F00-000 3674410F00000

Not available

BOLT

01550-0612B-000 015500612B000

$3,97

Unit Price

DISCONTINUE
LOCK SET

37000-26832-000 3700026832000

Not available

37110-26F03
SWITCH ASSY, IGNITION

37110-26F02-000 3711026F02000

Not available

14A

LOCK SET

37102-10870-000 3710210870000

Not available

14B

SWITCH ASSY, IGNITION

37110-10FB0-000 3711010FB0000

Not available

14C

37102-10882
LOCK SET

37102-10880-000 3710210880000

Not available

14D

37110-10FA1
SWITCH ASSY, IGNITION

37110-10FA0-000 3711010FA0000

Not available

BOLT

07130-0616B-000 071300616B000

$6,97

Unit Price

SWITCH ASSY, STOP LAMP

37740-10F00-000 3774010F00000

$52,97

Unit Price

SPRING, STOP LAMP SWITCH
SPRING, STOP LAMP

43139-10F00-000 4313910F00000

$10,97

Unit Price

SWITCH ASSY, SIDE STAND

37840-10F00-000

37840-10F01-000

$164,97

Unit Price

BOLT

01550-0620A-000 015500620A000

$3,97

Unit Price

HORN ASSY, RH

38501-10F00-000 3850110F00000

Not available

HORN ASSY, LH

38502-10F00-000 3850210F00000

Not available

CLAMP
CLAMP (L:33)

09407-03401-000 0940703401000

$5,97

Unit Price

HORN ASSY

38500-10F20-000 3850010F20000

$170,97

Unit Price

BOLT
BOLT, HORN

01550-0616B-000 015500616B000

$3,97

Unit Price

RELAY ASSY
RELAY ASSY, FUEL PUMP

38740-24X50-000 3874024X50000

$43,97

Unit Price

25A

RELAY ASSY
RELAY ASSY, HEAD LAMP

38740-24A00-000 3874024A00000

$60,97

Unit Price

KEY, BLANK

37146-48E00-000

37146-48E10-000

$45,97

Unit Price

26B

KEY, BLANK(BOULEVARD)
KEY, BLANK "BOULEVARD"

37146-10F00-000 3714610F00000

$80,97

Unit Price

26A

KEY, BLANK "INTRUDER"

37146-10F10-000 3714610F10000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
