FAIRING (VLR1800TK9) REFER TO FIG.44C(G- 5) FOR MODEL L0

FAIRING (MODEL L0) FOR SUZUKI INTRUDER 1800 2009

SIDE LOWER COVER

Item numbers

DISCONTINUE
COVER, FRAME RH (BLACK)

47110-22H00-YAY 4711022H00YAY

Not available

DISCONTINUE
COVER, FRAME RH (GRAY)

47110-22H00-YHG 4711022H00YHG

Not available

COVER, FRAME RH (BLACK)

47110-22H10-YAY 4711022H10YAY

Not available

COVER, FRAME RH (GRAY)

47110-22H10-YHG 4711022H10YHG

Not available

47110-22HA1-YAY
COVER, FRAME RH (BLACK)

47110-22HA0-YAY 4711022HA0YAY

Not available

COVER, FRAME RH (RED)

47110-22HA0-YMK 4711022HA0YMK

Not available

SHIELD, FRAME COVER, R
SHIELD, RH

47166-22H00-000 4716622H00000

$21,97

Unit Price

EMBLEM

68131-22H10-000 6813122H10000

Not available

68131-22H01
EMBLEM

68131-22H00-000 6813122H00000

Not available

68131-22HA1
EMBLEM

68131-22HA0-000 6813122HA0000

Not available

47210-22H01-YAY
COVER, FRAME LH (BLACK)

47210-22H00-YAY 4721022H00YAY

Not available

DISCONTINUE
COVER, FRAME LH (GRAY)

47210-22H00-YHG 4721022H00YHG

Not available

COVER, FRAME LH (BLACK)

47210-22H10-YAY 4721022H10YAY

Not available

COVER, FRAME LH (GRAY)

47210-22H10-YHG 4721022H10YHG

Not available

47210-22HA1-YAY
COVER, FRAME LH (BLACK)

47210-22HA0-YAY 4721022HA0YAY

Not available

COVER, FRAME LH (RED)

47210-22HA0-YMK 4721022HA0YMK

Not available

EMBLEM

68131-22H10-000 6813122H10000

Not available

68131-22H01
EMBLEM

68131-22H00-000 6813122H00000

Not available

68131-22HA1
EMBLEM

68131-22HA0-000 6813122HA0000

Not available

DISCONTINUE
BODY, LUGGAGE BOX

92211-22H00-000 9221122H00000

Not available

SCREW, 6X12
SCREW

09139-06152-000 0913906152000

$10,97

Unit Price

SCREW, 6X10
SCREW

09139-06172-000 0913906172000

$5,97

Unit Price

DISCONTINUE
LID

92212-22H00-000 9221222H00000

Not available

CUSHION(8X26X7)

09320-08018-000

09320-08513-000

$4,97

Unit Price

CUSHION

09320-08049-000 0932008049000

$6,97

Unit Price

LOCK SET, FRAME COVER

95700-07870-000 9570007870000

$191,97

Unit Price

BRACKET, FRAME COVER

47120-22H00-000 4712022H00000

$84,97

Unit Price

CUSHION(10X30X2)
CUSHION

44894-24A00-000 4489424A00000

$2,97

Unit Price

BOLT

01550-0610A-000

01550-0610B-000

$3,97

Unit Price

MOLDING, FRAME HEAD COVER
MOLDING

47514-10F00-000 4751410F00000

$16,97

Unit Price

DISCONTINUE
BAND, TOOL

09280-61002-000

Not available

TOOL ASSY

09800-21055-000

09800-21102-000

$49,97

Unit Price

SPANNER, HEXAGON(6)
HEXAGON, SPANNER 6

09816-00050-000 0981600050000

$10,97

Unit Price

HEXAGON, SPANNER 5

09816-00059-000 0981600059000

$10,97

Unit Price
