Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

FUEL TANK (MODEL K5)

FAIRING FOR SUZUKI DR-Z 250 2005

HEADLIGHT COVER (MODEL K1) REFER TO FIG.38A(F-14) FOR MODEL K2/K3/K4/K5

Item numbers
FAIRING Suzuki MOTO 250 DR-Z 2005 DR-Z250K5(E24)
1
1
1
2
3
4
4
4
5
6
7
7
8
9
10
11
1
COVER, FRAME, R(WHITE)
COVER, FRAME RH (WHITE)

47111-13E00-30H   4711113E0030H

4711113E0030H

Unit Price

1
COVER, FRAME, R(YELLOW)
COVER, FRAME RH (YELLOW)

47111-13E00-YU1   4711113E00YU1

4711113E00YU1

Unit Price

1
47111-13E00-YU1
COVER, FRAME RH (YELLOW)

47111-13E00-YR1   4711113E00YR1

4711113E00YR1
Not available
2
68131-13E11-FR4
EMBLEM, FRAME COVER RH

68131-13E10-FR4   6813113E10FR4

6813113E10FR4
Not available
3
SHIELD, FRAME COVER, R
SHIELD, FRAME COVER RH

47166-13E00-000   4716613E00000

4716613E00000

Unit Price

4
COVER, FRAME, L(WHITE)
COVER, FRAME LH (WHITE)

47211-13E00-30H   4721113E0030H

4721113E0030H

Unit Price

4
COVER, FRAME, L(YELLOW)
COVER, FRAME LH (YELLOW)

47211-13E00-YU1   4721113E00YU1

4721113E00YU1

Unit Price

4
COVER, FRAME LH (YELLOW)

47211-13E00-YR1   4721113E00YR1

4721113E00YR1
Not available
5
SCREW 6X12<br />SCREW
SCREW 6X12
SCREW

02142-06127-000   0214206127000

0214206127000

Unit Price

6
6X16CROSS SCREW<br />SCREW
6X16CROSS SCREW
SCREW

02142-06167-000   0214206167000

0214206167000

Unit Price

7
WASHER

09169-06028-000  

09169-06031-000
 0916906028000

Unit Price

8
FRAME COVER CUSHION
FRAME COVER CUSHION

09320-08013-000  

09320-08509-000
 0932008013000

Unit Price

9
CUSHION
CUSHION

09321-10018-000   0932110018000

0932110018000

Unit Price

10
SCREW

03541-15123-000  

03541-1512B-000
 0354115123000

Unit Price

11
NUT INST CENTER

09148-05004-000  

09148-05013-000
 0914805004000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for Suzuki 250 DR-Z 2005

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 250 DR-Z 2005

Choose your Suzuki 250 2005 DR-Z model

250 DR-Z 2005 DR-Z250K5(E24)

Suzuki DR-Z

Displacement: 250 cc
Year: 2005
Model code DR-Z250K5(E24)
