Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

CRANKSHAFT (MODEL K1 / K2) REFER TO FIG.5A(C-11) FOR MODEL K3/K4/K5/K6

CRANKSHAFT (MODEL K3 / K4 / K5 / K6) FOR SUZUKI RM 250 2003

CARBURETOR (MODEL K1) REFER TO FIG.6A(D- 5) FOR MODEL K2

Item numbers
CRANKSHAFT (MODEL K3/K4/K5/K6) Suzuki MOTO 250 RM 2003 RM250K3(E3/E28)
1
1
2
2
2
2
3
3
4
4
5
6
6
6
7
8
8
9
10
11
11
11
12
12
12
13
13
13
13
14
14
15B
15B
15
15A
15A
16
17
18
19
19
19
19
19
19
19
20
20
20
20
20
20
21
21
21
21
21
21
21
22
22
22
22
22
22
23
23
23
23
23
23
23
24
24
24
24
24
24
1
PISTON

12110-37F30-0F0   1211037F300F0

1211037F300F0

Unit Price

1
DISCONTINUE
PISTON

12110-37F20-0F0   1211037F200F0

1211037F200F0
Not available
2
RING, PISTON

12141-37E02-000   1214137E02000

1214137E02000

Unit Price

2
RING, PISTON

12141-37F00-000   1214137F00000

1214137F00000

Unit Price

3
PIN, PISTON

12151-28C00-000  

12151-37F00-000
 1215128C00000

Unit Price

4
PISTON PIN CIRCLIP<br />CIRCLIP
PISTON PIN CIRCLIP
CIRCLIP

09381-18002-000   0938118002000

0938118002000

Unit Price

5
BEARING, PISTON PIN
BEARING

09263-18031-000   0926318031000

0926318031000

Unit Price

6
CRANKSHAFT ASSY

12200-37F40-000   1220037F40000

1220037F40000

Unit Price

6
DISCONTINUE
CRANKSHAFT ASSY

12200-37F20-000   1220037F20000

1220037F20000
Not available
6
DISCONTINUE
CRANKSHAFT ASSY

12200-37F30-000   1220037F30000

1220037F30000
Not available
7
CONNECTING ROD
ROD, CONNECTING

12161-37F20-000   1216137F20000

1216137F20000

Unit Price

8
WASHER, CRANK PIN BEA
WASHER

09160-24033-000   0916024033000

0916024033000

Unit Price

9
PIN, CRANK

12210-37F20-000   1221037F20000

1221037F20000

Unit Price

10
BEARING<br />BEARING, CRANK PIN
BEARING
BEARING, CRANK PIN

09263-24026-000   0926324026000

0926324026000

Unit Price

11
CRANKSHAFT, R
CRANKSHAFT, RH

12220-37F40-000   1222037F40000

1222037F40000

Unit Price

11
DISCONTINUE
CRANKSHAFT, RH

12220-37F20-000   1222037F20000

1222037F20000
Not available
11
DISCONTINUE
CRANKSHAFT, RH

12220-37F30-000   1222037F30000

1222037F30000
Not available
12
DISCONTINUE
CRANKSHAFT, LH

12260-37F20-000   1226037F20000

1226037F20000
Not available
12
DISCONTINUE
CRANKSHAFT, LH

12260-37F30-000   1226037F30000

1226037F30000
Not available
12
DISCONTINUE
CRANKSHAFT, LH

12260-37F40-000   1226037F40000

1226037F40000
Not available
13
BEARING, 28X68X18
BEARING, CRANKSHAFT

09262-28027-000   0926228027000

0926228027000

Unit Price

13
BEARING, CRANKSHAFT

09262-28044-000   0926228044000

0926228044000

Unit Price

14
SEAL, CRANKSHAFT OIL,
OIL SEAL, CRANKSHAFT RH

09283-28024-000   0928328024000

0928328024000

Unit Price

14
SEAL, CSHAFT R O
OIL SEAL, CRANKSHAFT RH

09283-28025-000   0928328025000

0928328025000

Unit Price

15
SEAL, OIL CRANKS FAFT
OIL SEAL, CRANKSHAFT LH

09283-25099-000   0928325099000

0928325099000

Unit Price

15A
RETAINER, CRANKSHAFT BEARING

24741-37F00-000   2474137F00000

2474137F00000

Unit Price

15B
SCREW

02122-06123-000  

02122-0612B-000
 0212206123000

Unit Price

16
GEAR, PRIMARY DRIVE
GEAR, PRIMARY DRIVE (NT:21)

21111-37F20-000   2111137F20000

2111137F20000

Unit Price

17
BOLT, PRIMARY DRIVE G
BOLT, PRIMARY DRIVE GEAR

09103-10339-000   0910310339000

0910310339000

Unit Price

18
WASHER, PRIMARY DRIVE
WASHER

09164-11004-000   0916411004000

0916411004000

Unit Price

19
PISTON PIN CIRCLIP<br />CIRCLIP
PISTON PIN CIRCLIP
CIRCLIP

09381-18002-000   0938118002000

0938118002000

Unit Price

19
O RING, CYLINDER HEAD NO.1

11147-37F00-000   1114737F00000

1114737F00000

Unit Price

19
O RING, CYLINDER HEAD NO.2

11148-37F00-000   1114837F00000

1114837F00000

Unit Price

19
GASKET, CYLINDER

11241-37F20-000   1124137F20000

1124137F20000

Unit Price

19
RING, PISTON

12141-37E02-000   1214137E02000

1214137E02000

Unit Price

19
DISCONTINUE
TOP END KIT, ENGINE

12102-37820-000   1210237820000

1210237820000
Not available
19
DISCONTINUE
PISTON

12110-37F20-0F0   1211037F200F0

1211037F200F0
Not available
20
BEARING, PISTON PIN
BEARING

09263-18031-000   0926318031000

0926318031000

Unit Price

20
PISTON PIN CIRCLIP<br />CIRCLIP
PISTON PIN CIRCLIP
CIRCLIP

09381-18002-000   0938118002000

0938118002000

Unit Price

20
RING, PISTON

12141-37E02-000   1214137E02000

1214137E02000

Unit Price

20
PIN, PISTON

12151-37F00-000   1215137F00000

1215137F00000

Unit Price

20
DISCONTINUE
PISTON KIT

12110-37812-000   1211037812000

1211037812000
Not available
20
DISCONTINUE
PISTON

12110-37F20-0F0   1211037F200F0

1211037F200F0
Not available
21
PISTON PIN CIRCLIP<br />CIRCLIP
PISTON PIN CIRCLIP
CIRCLIP

09381-18002-000   0938118002000

0938118002000

Unit Price

21
O RING, CYLINDER HEAD NO.1

11147-37F00-000   1114737F00000

1114737F00000

Unit Price

21
O RING, CYLINDER HEAD NO.2

11148-37F00-000   1114837F00000

1114837F00000

Unit Price

21
GASKET, CYLINDER

11241-37F20-000   1124137F20000

1124137F20000

Unit Price

21
RING, PISTON

12141-37F00-000   1214137F00000

1214137F00000

Unit Price

21
DISCONTINUE

12102-37830-000  

1210237830000
Not available
21
DISCONTINUE
PISTON

12110-37F20-0F0   1211037F200F0

1211037F200F0
Not available
22
BEARING, PISTON PIN
BEARING

09263-18031-000   0926318031000

0926318031000

Unit Price

22
PISTON PIN CIRCLIP<br />CIRCLIP
PISTON PIN CIRCLIP
CIRCLIP

09381-18002-000   0938118002000

0938118002000

Unit Price

22
RING, PISTON

12141-37F00-000   1214137F00000

1214137F00000

Unit Price

22
PIN, PISTON

12151-37F00-000   1215137F00000

1215137F00000

Unit Price

22
DISCONTINUE
PISTON KIT

12110-37820-000   1211037820000

1211037820000
Not available
22
DISCONTINUE
PISTON

12110-37F20-0F0   1211037F200F0

1211037F200F0
Not available
23
PISTON PIN CIRCLIP<br />CIRCLIP
PISTON PIN CIRCLIP
CIRCLIP

09381-18002-000   0938118002000

0938118002000

Unit Price

23
O RING, CYLINDER HEAD NO.1
O RING, CYLINDER HEAD N

11147-37F00-000   1114737F00000

1114737F00000

Unit Price

23
O RING, CYLINDER HEAD NO.2
O RING, CYLINDER HEAD N

11148-37F00-000   1114837F00000

1114837F00000

Unit Price

23
GASKET, CYLINDER

11241-37F20-000   1124137F20000

1124137F20000

Unit Price

23
PISTON

12110-37F30-0F0   1211037F300F0

1211037F300F0

Unit Price

23
RING, PISTON

12141-37F00-000   1214137F00000

1214137F00000

Unit Price

23
DISCONTINUE
TOP END KIT, ENGINE

12102-37840-000   1210237840000

1210237840000
Not available
24
BEARING, PISTON PIN

09263-18031-000   0926318031000

0926318031000

Unit Price

24
PISTON PIN CIRCLIP<br />CIRCLIP
PISTON PIN CIRCLIP
CIRCLIP

09381-18002-000   0938118002000

0938118002000

Unit Price

24
PISTON

12110-37F30-0F0   1211037F300F0

1211037F300F0

Unit Price

24
RING, PISTON

12141-37F00-000   1214137F00000

1214137F00000

Unit Price

24
PIN, PISTON

12151-28C00-000  

12151-37F00-000
 1215128C00000

Unit Price

24
PISTON KIT

12110-37830-000   1211037830000

1211037830000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for Suzuki 250 RM 2003

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS
GASKET SET (MODEL K1/K2) for Suzuki RM 250 2003

GASKET SET (MODEL K1 / K2)
for Suzuki RM 250 2003

GASKET SET (MODEL K3/K4/K5/K6) for Suzuki RM 250 2003

GASKET SET (MODEL K3 / K4 / K5 / K6)
for Suzuki RM 250 2003

CYLINDER (MODEL K1) for Suzuki RM 250 2003

CYLINDER (MODEL K1)
for Suzuki RM 250 2003

CYLINDER (MODEL K2) for Suzuki RM 250 2003

CYLINDER (MODEL K2)
for Suzuki RM 250 2003

CYLINDER (MODEL K3/K4/K5/K6) for Suzuki RM 250 2003

CYLINDER (MODEL K3 / K4 / K5 / K6)
for Suzuki RM 250 2003

EXHAUST VALVE (MODEL K1) for Suzuki RM 250 2003

EXHAUST VALVE (MODEL K1)
for Suzuki RM 250 2003

EXHAUST VALVE (MODEL K2) for Suzuki RM 250 2003

EXHAUST VALVE (MODEL K2)
for Suzuki RM 250 2003

EXHAUST VALVE (MODEL K3/K4/K5/K6) for Suzuki RM 250 2003

EXHAUST VALVE (MODEL K3 / K4 / K5 / K6)
for Suzuki RM 250 2003

CRANKCASE (MODEL K1/K2) for Suzuki RM 250 2003

CRANKCASE (MODEL K1 / K2)
for Suzuki RM 250 2003

CRANKCASE (MODEL K3/K4/K5/K6) for Suzuki RM 250 2003

CRANKCASE (MODEL K3 / K4 / K5 / K6)
for Suzuki RM 250 2003

CRANKCASE COVER WATER PUMP (MODEL K1/K2) for Suzuki RM 250 2003

CRANKCASE COVER- WATER PUMP (MODEL K1 / K2)
for Suzuki RM 250 2003

CRANKCASE COVER WATER PUMP (MODEL K3/K4/K5/K6) for Suzuki RM 250 2003

CRANKCASE COVER-WATER PUMP (MODEL K3 / K4 / K5 / K6)
for Suzuki RM 250 2003

CRANKSHAFT (MODEL K1/K2) for Suzuki RM 250 2003

CRANKSHAFT (MODEL K1 / K2)
for Suzuki RM 250 2003

CRANKSHAFT (MODEL K3/K4/K5/K6) for Suzuki RM 250 2003

CRANKSHAFT (MODEL K3 / K4 / K5 / K6)
for Suzuki RM 250 2003

CARBURETOR (MODEL K1) for Suzuki RM 250 2003

CARBURETOR (MODEL K1)
for Suzuki RM 250 2003

CARBURETOR (MODEL K2) for Suzuki RM 250 2003

CARBURETOR (MODEL K2)
for Suzuki RM 250 2003

CARBURETOR (MODEL K3) for Suzuki RM 250 2003

CARBURETOR (MODEL K3)
for Suzuki RM 250 2003

CARBURETOR (MODEL K4) for Suzuki RM 250 2003

CARBURETOR (MODEL K4)
for Suzuki RM 250 2003

CARBURETOR (MODEL K5) for Suzuki RM 250 2003

CARBURETOR (MODEL K5)
for Suzuki RM 250 2003

CARBURETOR (MODEL K6) for Suzuki RM 250 2003

CARBURETOR (MODEL K6)
for Suzuki RM 250 2003

AIR FILTER (MODEL K1/K2) for Suzuki RM 250 2003

AIR FILTER (MODEL K1 / K2)
for Suzuki RM 250 2003

AIR FILTER (MODEL K3/K4/K5/K6) for Suzuki RM 250 2003

AIR FILTER (MODEL K3 / K4 / K5 / K6)
for Suzuki RM 250 2003

MUFFLER for Suzuki RM 250 2003

MUFFLER
for Suzuki RM 250 2003

RADIATOR for Suzuki RM 250 2003

RADIATOR
for Suzuki RM 250 2003

CLUTCH (MODEL K1/K2) for Suzuki RM 250 2003

CLUTCH (MODEL K1 / K2)
for Suzuki RM 250 2003

CLUTCH (MODEL K3/K4/K5) for Suzuki RM 250 2003

CLUTCH (MODEL K3 / K4 / K5)
for Suzuki RM 250 2003

CLUTCH (MODEL K6) for Suzuki RM 250 2003

CLUTCH (MODEL K6)
for Suzuki RM 250 2003

TRANSMISSION (MODEL K1/K2/K3) for Suzuki RM 250 2003

TRANSMISSION (MODEL K1 / K2 / K3)
for Suzuki RM 250 2003

TRANSMISSION (MODEL K4/K5/K6) for Suzuki RM 250 2003

TRANSMISSION (MODEL K4 / K5 / K6)
for Suzuki RM 250 2003

GEAR SHIFTING ASSY for Suzuki RM 250 2003

GEAR SHIFTING ASSY
for Suzuki RM 250 2003

KICK STARTER (MODEL K1/K2/K3/K4) for Suzuki RM 250 2003

KICK STARTER (MODEL K1 / K2 / K3 / K4)
for Suzuki RM 250 2003

KICK STARTER (MODEL K5/K6) for Suzuki RM 250 2003

KICK STARTER (MODEL K5 / K6)
for Suzuki RM 250 2003

FUEL COCK for Suzuki RM 250 2003

FUEL COCK
for Suzuki RM 250 2003

STAND FOOTREST (MODEL K1/K2) for Suzuki RM 250 2003

STAND - FOOTREST (MODEL K1 / K2)
for Suzuki RM 250 2003

STAND FOOTREST (MODEL K3/K4/K5/K6) for Suzuki RM 250 2003

STAND - FOOTREST (MODEL K3 / K4 / K5 / K6)
for Suzuki RM 250 2003

REAR BRAKE for Suzuki RM 250 2003

REAR BRAKE
for Suzuki RM 250 2003

HANDLEBAR (MODEL K1/K2/K3/K4) for Suzuki RM 250 2003

HANDLEBAR (MODEL K1 / K2 / K3 / K4)
for Suzuki RM 250 2003

HANDLEBAR (MODEL K5/K6) for Suzuki RM 250 2003

HANDLEBAR (MODEL K5 / K6)
for Suzuki RM 250 2003

LEVERS HANDGRIPS (MODEL K1/K2/K3) for Suzuki RM 250 2003

LEVERS - HANDGRIPS (MODEL K1 / K2 / K3)
for Suzuki RM 250 2003

LEVERS HANDGRIPS (MODEL K4/K5/K6) for Suzuki RM 250 2003

LEVERS - HANDGRIPS (MODEL K4 / K5 / K6)
for Suzuki RM 250 2003

FRONT FORK (MODEL K1) for Suzuki RM 250 2003

FRONT FORK (MODEL K1)
for Suzuki RM 250 2003

FRONT FORK (MODEL K2) for Suzuki RM 250 2003

FRONT FORK (MODEL K2)
for Suzuki RM 250 2003

FRONT FORK (MODEL K3) for Suzuki RM 250 2003

FRONT FORK (MODEL K3)
for Suzuki RM 250 2003

FRONT FORK (MODEL K4) for Suzuki RM 250 2003

FRONT FORK (MODEL K4)
for Suzuki RM 250 2003

FRONT FORK (MODEL K5) for Suzuki RM 250 2003

FRONT FORK (MODEL K5)
for Suzuki RM 250 2003

FRONT FORK (MODEL K6) for Suzuki RM 250 2003

FRONT FORK (MODEL K6)
for Suzuki RM 250 2003

STEERING COLUMN (MODEL K1) for Suzuki RM 250 2003

STEERING COLUMN (MODEL K1)
for Suzuki RM 250 2003

STEERING COLUMN (MODEL K2) for Suzuki RM 250 2003

STEERING COLUMN (MODEL K2)
for Suzuki RM 250 2003

STEERING COLUMN (MODEL K3) for Suzuki RM 250 2003

STEERING COLUMN (MODEL K3)
for Suzuki RM 250 2003

STEERING COLUMN (MODEL K4) for Suzuki RM 250 2003

STEERING COLUMN (MODEL K4)
for Suzuki RM 250 2003

STEERING COLUMN (MODEL K5) for Suzuki RM 250 2003

STEERING COLUMN (MODEL K5)
for Suzuki RM 250 2003

STEERING COLUMN (MODEL K6) for Suzuki RM 250 2003

STEERING COLUMN (MODEL K6)
for Suzuki RM 250 2003

FRONT WHEEL (MODEL K1/K2/K3/K4) for Suzuki RM 250 2003

FRONT WHEEL (MODEL K1 / K2 / K3 / K4)
for Suzuki RM 250 2003

FRONT WHEEL (RM250K5/K6) for Suzuki RM 250 2003

FRONT WHEEL (RM250K5 / K6)
for Suzuki RM 250 2003

FRONT WHEEL (RM250ZK6) for Suzuki RM 250 2003

FRONT WHEEL (RM250ZK6)
for Suzuki RM 250 2003

FRONT CALIPER (MODEL K1/K2/K3/K4) for Suzuki RM 250 2003

FRONT CALIPER (MODEL K1 / K2 / K3 / K4)
for Suzuki RM 250 2003

FRONT CALIPER (MODEL K5/K6) for Suzuki RM 250 2003

FRONT CALIPER (MODEL K5 / K6)
for Suzuki RM 250 2003

FRONT MASTER CYLINDER (MODEL K1/K2/K3) for Suzuki RM 250 2003

FRONT MASTER CYLINDER (MODEL K1 / K2 / K3)
for Suzuki RM 250 2003

FRONT MASTER CYLINDER (MODEL K4/K5/K6) for Suzuki RM 250 2003

FRONT MASTER CYLINDER (MODEL K4 / K5 / K6)
for Suzuki RM 250 2003

SWINGARM (MODEL K1/K2/K3) for Suzuki RM 250 2003

SWINGARM (MODEL K1 / K2 / K3)
for Suzuki RM 250 2003

SWINGARM (MODEL K4) for Suzuki RM 250 2003

SWINGARM (MODEL K4)
for Suzuki RM 250 2003

SWINGARM (MODEL K5/K6) for Suzuki RM 250 2003

SWINGARM (MODEL K5 / K6)
for Suzuki RM 250 2003

REAR SHOCK ABSORBER (MODEL K1/K2/K3) for Suzuki RM 250 2003

REAR SHOCK ABSORBER (MODEL K1 / K2 / K3)
for Suzuki RM 250 2003

REAR SHOCK ABSORBER (MODEL K4) for Suzuki RM 250 2003

REAR SHOCK ABSORBER (MODEL K4)
for Suzuki RM 250 2003

REAR SHOCK ABSORBER (MODEL K5) for Suzuki RM 250 2003

REAR SHOCK ABSORBER (MODEL K5)
for Suzuki RM 250 2003

REAR SHOCK ABSORBER (MODEL K6) for Suzuki RM 250 2003

REAR SHOCK ABSORBER (MODEL K6)
for Suzuki RM 250 2003

SHOCK ABSORBER LINKAGE (MODEL K1) for Suzuki RM 250 2003

SHOCK ABSORBER LINKAGE (MODEL K1)
for Suzuki RM 250 2003

SHOCK ABSORBER LINKAGE (MODEL K2/K3) for Suzuki RM 250 2003

SHOCK ABSORBER LINKAGE (MODEL K2 / K3)
for Suzuki RM 250 2003

SHOCK ABSORBER LINKAGE (MODEL K4/K5/K6) for Suzuki RM 250 2003

SHOCK ABSORBER LINKAGE (MODEL K4 / K5 / K6)
for Suzuki RM 250 2003

REAR WHEEL (MODEL K1/K2) for Suzuki RM 250 2003

REAR WHEEL (MODEL K1 / K2)
for Suzuki RM 250 2003

REAR WHEEL (MODEL K3) for Suzuki RM 250 2003

REAR WHEEL (MODEL K3)
for Suzuki RM 250 2003

REAR WHEEL (MODEL K4) for Suzuki RM 250 2003

REAR WHEEL (MODEL K4)
for Suzuki RM 250 2003

REAR WHEEL (MODEL K5) for Suzuki RM 250 2003

REAR WHEEL (MODEL K5)
for Suzuki RM 250 2003

REAR WHEEL (RM250K6) for Suzuki RM 250 2003

REAR WHEEL (RM250K6)
for Suzuki RM 250 2003

REAR WHEEL (RM250ZK6) for Suzuki RM 250 2003

REAR WHEEL (RM250ZK6)
for Suzuki RM 250 2003

REAR CALIPER (MODEL K1/K2/K3) for Suzuki RM 250 2003

REAR CALIPER (MODEL K1 / K2 / K3)
for Suzuki RM 250 2003

REAR CALIPER (MODEL K4) for Suzuki RM 250 2003

REAR CALIPER (MODEL K4)
for Suzuki RM 250 2003

REAR CALIPER (MODEL K5/K6) for Suzuki RM 250 2003

REAR CALIPER (MODEL K5 / K6)
for Suzuki RM 250 2003

REAR BRAKE MASTER CYLINDER (MODEL K1/K2) for Suzuki RM 250 2003

REAR BRAKE MASTER CYLINDER (MODEL K1 / K2)
for Suzuki RM 250 2003

REAR BRAKE MASTER CYLINDER (MODEL K3) for Suzuki RM 250 2003

REAR BRAKE MASTER CYLINDER (MODEL K3)
for Suzuki RM 250 2003

REAR BRAKE MASTER CYLINDER (MODEL K4) for Suzuki RM 250 2003

REAR BRAKE MASTER CYLINDER (MODEL K4)
for Suzuki RM 250 2003

REAR BRAKE MASTER CYLINDER (MODEL K5/K6) for Suzuki RM 250 2003

REAR BRAKE MASTER CYLINDER (MODEL K5 / K6)
for Suzuki RM 250 2003

Suzuki 250 RM 2003

Choose your Suzuki 250 2003 RM model

250 RM 2003 RM250K3(E3/E28)

Suzuki RM

Displacement: 250 cc
Year: 2003
Model code RM250K3(E3 / E28)
Drapeau USA
Usa
New and original manufacturer parts
Official Suzuki price
International delivery
Secure payment
Expert customer service
Other brands parts catalogues
