CLUTCH (MODEL K3 / K4 / K5) REFER TO FIG.10B(F- 4) FOR MODEL K6

CLUTCH (MODEL K6) FOR SUZUKI RM 250 2004

TRANSMISSION (MODEL K1 / K2 / K3) REFER TO FIG.11A(F- 7) FOR MODEL K4/K5/K6

Item numbers
CLUTCH (MODEL K6) Suzuki MOTO 250 RM 2004 RM250K4(E3/E28)
1
2
3
4
5
5
5
5
5
5
5
5
6
6
6
6
6
6
6
7
8
9
10
11
12
13
14
15
16
17
17
18
1
GEAR ASSY, PRI DRIVEN
GEAR ASSY, PRIMARY DRIVEN

21200-37F10-000   2120037F10000

2120037F10000

Unit Price

2
SPACER, PRIMARY DRIVEN GEAR

21251-37E01-000   2125137E01000

2125137E01000

Unit Price

3
BEARING, 29X34X27
BEARING, PRIMARY DRIVEN

09263-29009-000   0926329009000

0926329009000

Unit Price

4
HUB, CLUTCH SLEEVE

21410-37F50-000   2141037F50000

2141037F50000

Unit Price

5
PLATE, CLUTCH DRIVE

21441-37F50-000   2144137F50000

2144137F50000

Unit Price

6
PLATE, CLUTCH DRIVEN

21451-37F00-000   2145137F00000

2145137F00000

Unit Price

7
DISC, CLUTCH PRESSURE
DISK, CLUTCH PRESSURE

21462-37F20-000   2146237F20000

2146237F20000

Unit Price

8
BOLT, 5X18
BOLT, CLUTCH (5X25)

09116-05019-000   0911605019000

0911605019000

Unit Price

9
NUT
NUT, CLUTCH SLEEVE HUB

09140-18013-000   0914018013000

0914018013000

Unit Price

10
WASHER, 22.5X39X3
WASHER, CLUTCH HUB THR

09160-22082-000   0916022082000

0916022082000

Unit Price

11
WASHER, LOCK
WASHER, CLUTCH HUB

09167-22027-000   0916722027000

0916722027000

Unit Price

12
SPRING, CLUTCH

09440-18038-000   0944018038000

0944018038000

Unit Price

13
ROD, CLUTCH PUSH

23110-37F00-000   2311037F00000

2311037F00000

Unit Price

14
PIECE, CLUTCH PUSH

23121-37F00-000   2312137F00000

2312137F00000

Unit Price

15
CAMSHAFT, CLUTCH RELEASE

23200-37E02-000   2320037E02000

2320037E02000

Unit Price

16
RD SFT ARM PIN BRG
BEARING, CLUTCH RELEASE

09263-10002-000   0926310002000

0926310002000

Unit Price

17
BEARING
BEARING, NO.2

09263-12024-000   0926312024000

0926312024000

Unit Price

18
OIL SEAL CL RELEASE
SEAL, CL RELEASE CAMSHAFT

09285-12004-000   0928512004000

0928512004000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for Suzuki 250 RM 2004
