LEFT SWITCH - HANDGRIP FOR SUZUKI QUADRACER 250 1985

* CATALOG PREFACE *

LEFT SWITCH - HANDGRIP Suzuki QUAD 250 QUADRACER 1985 LT250RF(E28)
1
GRIP

57211-19A03-291  

57211-19A04-291
 5721119A03291

Unit Price

2
DISCONTINUE
LEVER ASSY, CLUTCH & PARKING

57800-19A01-000   5780019A01000

5780019A01000
Not available
3
DISCONTINUE
LEVER

57620-19A00-000   5762019A00000

5762019A00000
Not available
4
BOLT, LEVER SET

57431-33450-000  

57531-14A00-000
 5743133450000

Unit Price

5
SHIM
WASHER

08221-08144-000   0822108144000

0822108144000

Unit Price

6
WASHER, 6.5X15X1.6

57912-19A00-000  

09160-06128-000
 5791219A00000

Unit Price

7
NUT

08319-21065-000  

08319-21063-000
 0831921065000

Unit Price

8
DISCONTINUE
BRACKET

57512-44500-000   5751244500000

5751244500000
Not available
9
BOLT

01107-06205-000  

01500-06257-000
 0110706205000

Unit Price

10
ADJUSTER, CABLE

57441-13A00-000  

57441-26010-000
 5744113A00000

Unit Price

11
NUT, CABLE ADJUSTER

57442-44400-000  

57442-11010-000
 5744244400000

Unit Price

12
DISCONTINUE
SPRING

57817-19A00-000   5781719A00000

5781719A00000
Not available
13
DISCONTINUE
BUTTON

57811-19A00-000   5781119A00000

5781119A00000
Not available
14
DISCONTINUE
COVER

57815-19A00-000   5781519A00000

5781519A00000
Not available
15
DISCONTINUE
SCREW

57619-19A00-000   5761919A00000

5761919A00000
Not available
16
DISCONTINUE
PIECE

57814-19A00-000   5781419A00000

5781419A00000
Not available
17
PIN

57813-19A00-000   5781319A00000

5781319A00000

Unit Price

18
SPRING

57818-19A00-000   5781819A00000

5781819A00000

Unit Price

19
DISCONTINUE
LEVER, PARKING

57812-19A00-000   5781219A00000

5781219A00000
Not available
20
DISCONTINUE
SPRING, RETURN

57911-19A00-000   5791119A00000

5791119A00000
Not available
21
COVER, SPRING

57819-19A00-000   5781919A00000

5781919A00000
Not available
22
RING

08332-11045-000  

08332-11043-000
 0833211045000

Unit Price

23
DISCONTINUE
SWITCH ASSY, LH

37400-19A01-000   3740019A01000

3740019A01000
Not available
23
DISCONTINUE
SWITCH ASSY, LH

37400-19A10-000   3740019A10000

3740019A10000
Not available
24
SCREW

02112-05357-000   0211205357000

0211205357000

Unit Price

25
FUEL HOSE CLAMP<br />BAND
FUEL HOSE CLAMP
BAND

09407-12402-000   0940712402000

0940712402000

Unit Price

26
DISCONTINUE
COVER

57541-19A00-000   5754119A00000

5754119A00000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the LEFT SWITCH - HANDGRIP of your Suzuki of QUADRACER. Let us know if you have any questions.
