SEAT LOCK FOR SUZUKI BURGMAN 400 2016

STARTER MOTOR

Item numbers
SEAT LOCK Suzuki SCOOTER 400 BURGMAN 2016 AN400A L6 (E19)
1
2
3
4
5
6
7
8
9
10
11
12
13
1
BRACKET, SEAT HINGE

45240-05H01-000   4524005H01000

4524005H01000

Unit Price

2
NUT

08316-1006A-000   083161006A000

083161006A000

Unit Price

3
BRACKET, SEAT SUPPORT

45220-05H00-000   4522005H00000

4522005H00000

Unit Price

4
BOLT
SCREW (6X16)

09139-06139-000   0913906139000

0913906139000

Unit Price

5
CABLE, SEAT LOCK

45280-05H02-000   4528005H02000

4528005H02000

Unit Price

6
BOLT, SEAT HINGE BRKT

45215-05H00-000   4521505H00000

4521505H00000

Unit Price

7
LOCK ASSY, SEAT STRIKER

45700-14FD2-000   4570014FD2000

4570014FD2000

Unit Price

8
SNAP PIN

09385-05004-000   0938505004000

0938505004000
Not available
9
CLAMP

09403-07331-000   0940307331000

0940307331000

Unit Price

10
BOLT

01550-1016A-000   015501016A000

015501016A000

Unit Price

11
CLAMP

09407-19401-000  

09407-22403-000
 0940719401000

Unit Price

12
BAND,WIRING HARNESS<br />CLAMP (L:125)
BAND, WIRING HARNESS
CLAMP (L:125)

09407-14403-000   0940714403000

0940714403000

Unit Price

13
CUSHION, STEERING LOCK

45289-05H00-000   4528905H00000

4528905H00000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SEAT LOCK of your Suzuki BURGMAN 400 ABS of BURGMAN. Let us know if you have any questions.
