Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

FRAME (RM-Z450K8 / K9)

FRAME (RM-Z450L0) FOR SUZUKI RM-Z 450 2012

FRAME (RM-Z450L1)

Item numbers
FRAME (RM-Z450L0) Suzuki MOTO 450 RM-Z 2012 RM-Z450L1(E19)
1
2
3
4
5
6
6
7
8
9
10
11
11
12
13
14
14
15
16
17
18
19
20
1
DISCONTINUE
FRAME

41100-28H10-000  

4110028H10000
Not available
2
RAIL, SEAT

41200-28H20-000  

41200-28H40-000
 4120028H20000

Unit Price

3
BOLT, SEAT RAIL UPR
BOLT, UPPER

41311-28H20-000   4131128H20000

4131128H20000

Unit Price

4
NUT
NUT

08319-3108A-000   083193108A000

083193108A000

Unit Price

5
BOLT (8X23)

09103-08506-000   0910308506000

0910308506000

Unit Price

6
BRACKET, ENGINE MOUNTING FR
BRACKET, ENGINE MOUNT FRONT

41991-28H10-000   4199128H10000

4199128H10000

Unit Price

7
BOLT (10X135)

09103-10403-000   0910310403000

0910310403000

Unit Price

8
NUT
NUT

09159-10115-000   0915910115000

0915910115000

Unit Price

9
BRACKET, ENGINE MOUNTING UPR, R

41993-28H00-000  

41930-28H30-000
 4199328H00000

Unit Price

10
BRACKET, ENGINE MOUNTING UPR, L

41994-28H00-000  

41940-28H30-000
 4199428H00000

Unit Price

11
BOLT (8X21)

09103-08404-000   0910308404000

0910308404000

Unit Price

12
PROTECTOR, FR, R

42520-28H00-000  

42520-28H01-000
 4252028H00000

Unit Price

13
PROTECTOR, FR, L
PROTECTOR, FRONT LH

42530-28H10-000   4253028H10000

4253028H10000

Unit Price

14
BOLT (6X25)

09116-06177-000   0911606177000

0911606177000

Unit Price

15
ROLLER, CHAIN
ROLLER, CHAIN UPPER

43910-37F00-000   4391037F00000

4391037F00000

Unit Price

16
WASHER,THRUST<br />WASHER (8X16X1)
WASHER, THRUST
WASHER (8X16X1)

09181-08167-000   0918108167000

0918108167000

Unit Price

17
BOLT (8X45)

09103-08207-000   0910308207000

0910308207000

Unit Price

18
ROLLER, CHAIN
ROLLER, CHAIN LOWER

43910-35G00-000   4391035G00000

4391035G00000

Unit Price

19
WASHER
WASHER (8X12X1)

09181-08111-000   0918108111000

0918108111000

Unit Price

20
NUT
NUT

08319-2108A-000   083192108A000

083192108A000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME (RM-Z450L0) of your Suzuki of RM-Z. Let us know if you have any questions.
