FRAME FOR SUZUKI RMX-Z 450 2010

FOOTREST

Item numbers

FRAME

41100-02J00-000 4110002J00000

Not available

RAIL, SEAT

41200-02J00-000 4120002J00000

$1 098,97

Unit Price

BOLT, SEAT RAIL UPR
BOLT, UPPER

41311-28H20-000 4131128H20000

$25,97

Unit Price

NUT

08319-3108A-000 083193108A000

$3,97

Unit Price

BOLT, 8X20
BOLT, LOWER

09103-08426-000 0910308426000

$7,97

Unit Price

CAP
CAP, HEAD PLUG

09250-05009-000 0925005009000

$3,97

Unit Price

BRACKET, ENGINE MOUNTING FR
BRACKET, ENGINE MOUNT FRONT

41991-02J00-000 4199102J00000

$42,97

Unit Price

BOLT
BOLT, FRONT

09103-10388-000 0910310388000

$9,97

Unit Price

WASHER

09160-10039-000 0916010039000

$3,97

Unit Price

NUT

09159-10115-000 0915910115000

$5,97

Unit Price

BRACKET, ENGINE MOUNT UPPER RH

41993-28H10-000 4199328H10000

Not available

BRACKET, ENGINE MOUNT UPPER LH

41994-02J10-000 4199402J10000

Not available

BOLT(8X21)
BOLT, UPPER

09103-08404-000 0910308404000

$5,97

Unit Price

PROTECTOR, ENGINE
PROTECTOR, FRONT

42511-02J00-000 4251102J00000

$72,97

Unit Price

WASHER, ENGINE PROTECTOR
WASHER

42514-02J00-000 4251402J00000

$8,97

Unit Price

BOLT, 6X25
BOLT

09116-06177-000 0911606177000

$3,97

Unit Price

ROLLER, CHAIN
ROLLER, CHAIN UPPER

43910-37F00-000 4391037F00000

$71,97

Unit Price

WASHER, THRUST
WASHER, UPPER

09181-08167-000 0918108167000

$3,97

Unit Price

BOLT, 8 X 45
BOLT, UPPER

09103-08207-000 0910308207000

$3,97

Unit Price

ROLLER, CHAIN
ROLLER, CHAIN LOWER

43910-35G00-000 4391035G00000

$88,97

Unit Price

WASHER
WASHER, LOWER

09181-08111-000 0918108111000

$3,97

Unit Price

NUT
NUT, LOWER

08319-2108A-000 083192108A000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your Suzuki of RMX-Z. Let us know if you have any questions.
