WIRING HARNESS (E4,E15)

RIGHT SWITCH - HANDGRIP FOR SUZUKI TS-X 50 1988

LEFT SWITCH - HANDGRIP

Item numbers
RIGHT SWITCH - HANDGRIP Suzuki MOTO 50 TS-X 1988 TS50XKJ(E1)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
GRIP, THROTTLE

57110-13600-000   5711013600000

5711013600000

Unit Price

2
CASE ASSY, THROTTLE

57100-13601-000  

57100-13610-000
 5710013601000

Unit Price

3
57122-13610
PIECE, GUIDE

57122-13600-000   5712213600000

5712213600000
Not available
4
COVER, THROTTLE CASE
COVER

57129-13601-000   5712913601000

5712913601000

Unit Price

5
SCREW

02122-04103-000  

02122-0410A-000
 0212204103000

Unit Price

6
SCREW
SCREW

02112-05167-000   0211205167000

0211205167000

Unit Price

7
BRAKE LEVER / SWITCH ASSY

57300-13600-000   5730013600000

5730013600000
Not available
8
LEVER, BRAKE

57420-48700-000   5742048700000

5742048700000
Not available
9
BOLT,LEVER PIVOT<br />BOLT
BOLT, LEVER PIVOT
BOLT

57431-11013-000  

5743111013000
Not available
10
NUT

08319-21068-000  

08319-2106A-000
 0831921068000

Unit Price

11
ADJUSTER, CABLE
ADJUSTER, CABLE

57441-11010-000   5744111010000

5744111010000

Unit Price

12
NUT,CABLE ADJUSTER<br />NUT, CABLE ADJUSTER LOCK
NUT, CABLE ADJUSTER
NUT, CABLE ADJUSTER LOCK

57442-11010-000   5744211010000

5744211010000

Unit Price

13
SCREW
SCREW

02112-06207-000   0211206207000

0211206207000

Unit Price

14
SWITCH ASSY, STOP
STOP SWITCH

57460-10400-000   5746010400000

5746010400000
Not available
15
57341-25602
DUST SEAL

57341-25601-000  

5734125601000
Not available
16
FUEL HOSE CLAMP<br />CLAMP
FUEL HOSE CLAMP
CLAMP

09407-12402-000   0940712402000

0940712402000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the RIGHT SWITCH - HANDGRIP of your Suzuki of TS-X. Let us know if you have any questions.

Genuine parts for Suzuki 50 TS-X 1988

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 50 TS-X 1988

Select your Suzuki 1988 model

50 TS-X 1988 TS50XKJ(E1)

Suzuki TS-X

Displacement: 50 cc
Year: 1988
Model code TS50XKJ(E1)
