FOOTREST (AE50L / M / N / P) REFER TO FIG.29A(F-6) FOR AE50RP/RR/RS/RT/RV

FOOTREST (AE50RP / RR / RS / RT / RV) FOR SUZUKI AE 50 1992

FRONT FENDER

Item numbers

DISCONTINUE
SHIELD, LEG REAR (PURPLE)

48121-36C10-1FF 4812136C101FF

Not available

DISCONTINUE
SHIELD, LEG REAR (BLACK)

48121-36C10-291 4812136C10291

Not available

SCREW

03241-05123-000

03241-0512A-000

$2,97

Unit Price

SCREW

03241-05163-000

03241-0516A-000

$2,97

Unit Price

NUT

09148-05020-000 0914805020000

$3,97

Unit Price

BOLT(6X16)
BOLT

09111-06065-000 0911106065000

$3,97

Unit Price

BOLT

09111-06066-000 0911106066000

$4,97

Unit Price

DISCONTINUE
SHIELD, LEG LOWER RH (BLACK)

48291-36C10-019 4829136C10019

Not available

DISCONTINUE
SHIELD, LEG LOWER LH (BLACK)

48292-36C10-019 4829236C10019

Not available

SCREW

03241-05163-000

03241-0516A-000

$2,97

Unit Price

NUT

09148-05020-000 0914805020000

$3,97

Unit Price

SCREW

03541-04163-000

03541-0416A-000

$2,97

Unit Price

NUT

09148-04024-000 0914804024000

$3,97

Unit Price

DISCONTINUE
SHIELD, LEG LOWER CENTER (BLACK)

48139-36C00-019 4813936C00019

Not available

DISCONTINUE
SHIELD, LEG SIDE RH (BLACK)

48285-36C10-019 4828536C10019

Not available

DISCONTINUE
SHIELD, LEG SIDE LH (BLACK)

48286-36C10-019 4828636C10019

Not available

DISCONTINUE
BRACE, FRONT

48170-36C00-000 4817036C00000

Not available

BRACE, REAR

48180-36C00-000 4818036C00000

Not available

BRACE, REAR

48180-36C10-000 4818036C10000

Not available

GUARD, LEG SIDE

48186-36C00-000 4818636C00000

Not available

SCREW

02142-05103-000

02142-0510A-000

$2,97

Unit Price

SCREW

03541-04103-000

03541-0410A-000

$2,97

Unit Price

SCREW

03541-04163-000

03541-0416A-000

$2,97

Unit Price

NUT

09148-04024-000 0914804024000

$3,97

Unit Price

SCREW

03241-05163-000

03241-0516A-000

$2,97

Unit Price

NUT

09148-05020-000 0914805020000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FOOTREST (AE50RP/RR/RS/RT/RV) of your Suzuki of AE. Let us know if you have any questions.
