SEAT ASSY (MODEL K1 / K2)

SEAT ASSY (MODEL K3) FOR SUZUKI KATANA 50 2004

SEAT ASSY (MODEL K4)

Item numbers
SEAT ASSY (MODEL K3) Suzuki SCOOTER 50 KATANA 2004 AY50K4(P19)
1
1
2
3
4
5
6
7
7
7
8
9
10
11
12
13
14
15
15
15
15
16
16
17
17
17
1
SEAT SET (BLACK/GREY)

45100-35E40-000   4510035E40000

4510035E40000
Not available
1
SEAT SET (BLACK/GREY)

45100-35E50-000   4510035E50000

4510035E50000
Not available
2
CUSHION
CUSHION

09321-10012-000   0932110012000

0932110012000

Unit Price

3
BAND, SEAT (BLACK)

45180-35E00-NE2   4518035E00NE2

4518035E00NE2
Not available
4
SCREW

D2116-06255-000   D211606255000

D211606255000
Not available
5
NUT 6MM

D8310-00065-000  

08316-10063-000
 D831000065000

Unit Price

6
SCREW

D3111-05135-000   D311105135000

D311105135000
Not available
7
COVER, SEAT TAIL (BLUE)

45551-35E60-1LF   4555135E601LF

4555135E601LF
Not available
7
COVER, SEAT TAIL (BLACK)

45551-35E60-Y7L   4555135E60Y7L

4555135E60Y7L
Not available
8
CUSHION, COVER

45555-35E00-000   4555535E00000

4555535E00000
Not available
9
MOLDING, SEAT

45211-35E00-000   4521135E00000

4521135E00000
Not available
10
BRACKET, FRONT HINGE

45285-02E00-E0A   4528502E00E0A

4528502E00E0A
Not available
11
BOLT, FRONT

45215-09E01-E0N   4521509E01E0N

4521509E01E0N
Not available
12
NUT

D8316-10065-000   D831610065000

D831610065000
Not available
13
LOCK ASSY, SEAT

45700-09EF0-000   4570009EF0000

4570009EF0000
Not available
14
SCREW

D2116-06165-000  

02112-0616A-000
 D211606165000

Unit Price

15
SPOILER, REAR (BLUE)

47391-02E60-YC2   4739102E60YC2

4739102E60YC2
Not available
15
SPOILER, REAR (SILVER)

47391-02E60-YD8   4739102E60YD8

4739102E60YD8
Not available
15
SPOILER, REAR (BLUE)

47391-35E50-1LF   4739135E501LF

4739135E501LF
Not available
15
SPOILER, REAR (VIOLET)

47391-35E50-1TU   4739135E501TU

4739135E501TU
Not available
16
WING, REAR SPOILER (BLUE)

47392-35E50-1LF   4739235E501LF

4739235E501LF
Not available
16
WING, REAR SPOILER (VIOLET)

47392-35E50-1TU   4739235E501TU

4739235E501TU
Not available
17
SCREW

D2116-06205-000  

02112-0620A-000
 D211606205000

Unit Price

17
CARRIER SET

46311-35E00-000   4631135E00000

4631135E00000
Not available
17
TOP CASE

99000-35E00-KAT   9900035E00KAT

9900035E00KAT
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
