FRAME FOR SUZUKI DR 500 1987

FOOTREST

FRAME Suzuki MOTO 500 DR 1987 DR500RH(G/H/J)
1
FRAME (BLACK)

41100-14A00-019   4110014A00019

4110014A00019
Not available
1
FRAME (BLUE)

41100-14A00-19F   4110014A0019F

4110014A0019F
Not available
1
FRAME (BLACK)

41100-14A30-019   4110014A30019

4110014A30019
Not available
1
FRAME (BLUE)

41100-14A30-34S   4110014A3034S

4110014A3034S
Not available
1
FRAME (BLACK)

41100-14C00-019   4110014C00019

4110014C00019
Not available
1
FRAME (BLACK)

41100-14C00-34S   4110014C0034S

4110014C0034S
Not available
1
FRAME (WHITE)

41100-15A00-10V   4110015A0010V

4110015A0010V
Not available
1
FRAME (BLUE)

41100-15A30-34S   4110015A3034S

4110015A3034S
Not available
2
CAP, CUSHION LEVER

41499-14A00-10V  

41499-14A00-019
 4149914A0010V

Unit Price

2
CAP, CUSHION LEVER (BLUE)

41499-14A00-19F   4149914A0019F

4149914A0019F
Not available
3
PLATE, FRONT RH (BLACK)

41911-14A00-291   4191114A00291

4191114A00291
Not available
4
PLATE, FRONT LH (BLACK)

41921-14A00-291   4192114A00291

4192114A00291
Not available
5
ENGINE MOUNT BOLT
BOLT, UPPER

09103-08037-000   0910308037000

0910308037000

Unit Price

6
BOLT, LOWER

09103-08063-000   0910308063000

0910308063000
Not available
7
8 MM LOCK WASHER

08321-31087-000  

08321-01087-000
 0832131087000

Unit Price

8
NUT

08319-21088-000  

08319-2108A-000
 0831921088000

Unit Price

9
PLATE, UPPER (BLACK)

41991-14A00-291   4199114A00291

4199114A00291
Not available
10
BOLT

01517-08508-000  

01550-08507-000
 0151708508000

Unit Price

11
NUT
NUT

08319-31087-000   0831931087000

0831931087000
Not available
12
PLATE, REAR RH (BLACK)

41940-14A00-291   4194014A00291

4194014A00291
Not available
13
PLATE, REAR LH (BLACK)

41950-14A00-291   4195014A00291

4195014A00291
Not available
14
BOLT

01517-08207-000  

01550-08207-000
 0151708207000

Unit Price

15
8 MM LOCK WASHER

08321-31087-000  

08321-01087-000
 0832131087000

Unit Price

16
DISCONTINUE

42511-14A01-000  

4251114A01000
Not available
17
DISCONTINUE

42511-14A10-000  

4251114A10000
Not available
18
CUSHION
CUSHION

09321-10017-000   0932110017000

0932110017000

Unit Price

19
BOLT

01107-06207-000  

01500-06207-000
 0110706207000

Unit Price

20
BOLT

01517-08167-000  

01550-0816B-000
 0151708167000

Unit Price

21
WASHER, LOCK

08321-31067-000  

08321-01067-000
 0832131067000

Unit Price

22
WASHER(6.5X20X1.6)

09160-06020-000  

09160-06066-000
 0916006020000

Unit Price

23
SPACER, 6.5X9X7

09180-07005-000  

09180-06259-000
 0918007005000

Unit Price

24
CUSHION (8.5X20X8)
CUSHION (8.5X20X8)

09320-08021-000  

09320-08510-000
 0932008021000

Unit Price

25
ROLLER, CHAIN

43910-01B00-000  

43910-27C11-000
 4391001B00000

Unit Price

26
BOLT

01107-08408-000  

01500-08403-000
 0110708408000

Unit Price

27
8 MM LOCK WASHER

08321-31087-000  

08321-01087-000
 0832131087000

Unit Price

28
SPACER 8X6X12X25.5

09180-08119-000  

09180-08156-000
 0918008119000

Unit Price

29
WASHER, THRUST

08211-08161-000  

09181-08167-000
 0821108161000

Unit Price

30
DISCONTINUE
ROLLER, CHAIN LOWER

43911-14200-000   4391114200000

4391114200000
Not available
31
DISCONTINUE
BOLT, LOWER

43915-14A00-000   4391514A00000

4391514A00000
Not available
32
NUT
NUT

08319-31107-000   0831931107000

0831931107000

Unit Price

33
WASHER

08322-21128-000  

08322-01127-000
 0832221128000

Unit Price

34
DISCONTINUE
WASHER, OUTER

49317-15A00-000   4931715A00000

4931715A00000
Not available
35
PIN

04111-25208-000  

04111-2520A-000
 0411125208000

Unit Price

36
DISCONTINUE
HOLDER, TOOL

41550-37210-000   4155037210000

4155037210000
Not available
37
CAP, HOLDER
CAP

41552-37210-000   4155237210000

4155237210000

Unit Price

38
BOLT

01107-06165-000  

01500-06163-000
 0110706165000

Unit Price

39
WASHER

09160-06039-000  

09160-06109-000
 0916006039000

Unit Price

40
09800-21024
TOOL ASSY

09800-00242-000  

0980000242000
Not available
41
GUARD, HEADLAMP

48510-14A01-000   4851014A01000

4851014A01000
Not available
42
BRACE, HEADLAMP GUARD

48520-14A00-000   4852014A00000

4852014A00000
Not available
43
SCREW

02142-06125-000  

02142-0612B-000
 0214206125000

Unit Price

44
WASHER

09160-06069-000  

09160-06052-000
 0916006069000

Unit Price

45
NUT

08319-21065-000  

08319-21063-000
 0831921065000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your Suzuki of DR. Let us know if you have any questions.

Genuine parts for Suzuki 500 DR 1987
