SWINGARM

REAR SHOCK ABSORBER (MODEL E) FOR SUZUKI GSX-E 500 1984

REAR SHOCK ABSORBER (MODEL F)

REAR SHOCK ABSORBER (MODEL E) Suzuki MOTO 500 GSX-E 1984 GSX500ESE(E39)

1

SHOCK ABSORBER ASSY, REAR

62100-43410-000 6210043410000

Not available

1

SHOCK ABSORBER ASSY, REAR

62100-43450-000 6210043450000

Not available

2

BEARING, PISTON PIN
BEARING

09269-10003-000 0926910003000

$73,97

Unit Price

3

RING, STOPPER

62277-14200-000

62657-34A01-000

$3,97

Unit Price

4

DUST SEAL, RR CUSHION LEVER RR
COLLAR

62683-43400-000 6268343400000

$7,97

Unit Price

4

DUST SEAL

62226-43400-000 6222643400000

Not available

5

DISCONTINUE
DOLLAR

62187-43400-000 6218743400000

Not available

6

BOLT(10X115)
BOLT, LOWER

09103-10063-000 0910310063000

$11,97

Unit Price

7

NUT

08319-31108-000

08319-31107-000

$4,97

Unit Price

8

BRACKET

62411-43402-000 6241143402000

Not available

9

SCREW, FRONT FENDER

02112-06165-000 0211206165000

Not available

10

LOCK WASHER

08321-21065-000 0832121065000

Not available

11

WASHER

08322-21064-000

08322-0106A-000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the REAR SHOCK ABSORBER (MODEL E) of your Suzuki of GSX-E. Let us know if you have any questions.
