MUFFLER

OIL PUMP FOR SUZUKI BOULEVARD 650 2011

CLUTCH

Item numbers
OIL PUMP Suzuki MOTO 650 BOULEVARD 2011 LS650L1(E3/E28)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
PUMP ASSY, ENGINE OIL

16400-24B00-000   1640024B00000

1640024B00000

Unit Price

2
GEAR, ENG OIL PUMP DRIVEN
GEAR, DRIVEN (NT:35)

16331-24B00-000   1633124B00000

1633124B00000

Unit Price

3
GR SHIFT CAM DR PIN<br />PIN
GR SHIFT CAM DR PIN
PIN

09261-04009-000   0926104009000

0926104009000

Unit Price

4
SHIM (10X18X0.5)
SHIM (10X18X0.5)

09181-10158-000   0918110158000

0918110158000

Unit Price

5
CIRCLIP

08331-3110A-000  

08331-31109-000
 083313110A000

Unit Price

6
SCREW
SCREW

02112-0625A-000   021120625A000

021120625A000

Unit Price

7
STRAINER, ENGINE OIL

16520-24B00-000   1652024B00000

1652024B00000

Unit Price

8
BOLT

01580-0512A-000   015800512A000

015800512A000

Unit Price

9
FILTER ASSY, ENGINE OIL
FILTER, ENGINE OIL

16510-37450-000   1651037450000

1651037450000

Unit Price

10
O RING (D:2.4,ID:15.8)
O RING (D:2.4, ID:15.8)

09280-15007-000   0928015007000

0928015007000
Not available
11
CAP, OIL FILTER

16512-24B00-000   1651224B00000

1651224B00000

Unit Price

12
O RING OIL FLT CAP
O RING (D:2.4, ID:73.0)

09280-72001-000   0928072001000

0928072001000
Not available
13
SPRING

09440-21006-000   0944021006000

0944021006000

Unit Price

14
BOLT, CL COVER 1ST GR
BOLT (6X25)

09106-06090-000   0910606090000

0910606090000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the OIL PUMP of your Suzuki of BOULEVARD. Let us know if you have any questions.

Genuine parts for Suzuki 650 BOULEVARD 2011

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 650 BOULEVARD 2011

Select your Suzuki 2011 model

650 BOULEVARD 2011 LS650L1(E3/E28)

Suzuki BOULEVARD

Displacement: 650 cc
Year: 2011
Model code LS650L1(E3 / E28)
