FRONT TURNSIGNAL LAMP

TAIL LIGHT FOR SUZUKI FB 80 1989

WIRING HARNESS

Item numbers
TAIL LIGHT Suzuki SCOOTER 80 FB 1989 FB80K(E1)
1
2
3
4
5
6
7
7
8
9
9
10
10
10
10
11
12
13
14
15
16
17
1
LAMP ASSY, REAR COMBINATION

35710-09413-999   3571009413999

3571009413999
Not available
2
LENS, TAIL/STOP

35712-09400-000   3571209400000

3571209400000
Not available
3
GASKET

35713-09400-000   3571309400000

3571309400000
Not available
4
SCREW
SCREW

03212-04169-000   0321204169000

0321204169000

Unit Price

5
LENS, TURNSIGNAL RH

35652-09400-000   3565209400000

3565209400000
Not available
6
LENS, TURNSIGNAL LH

35672-09400-000   3567209400000

3567209400000
Not available
7
GASKET

35613-09400-000   3561309400000

3561309400000
Not available
8
SCREW

02112-04106-000  

02112-0410A-000
 0211204106000

Unit Price

9
BULB (6V, 10/3W)

09471-06008-000   0947106008000

0947106008000
Not available
9
BULB (12V, 20/5W)

09471-12008-000   0947112008000

0947112008000
Not available
10
BULB(6V25/25W,STANLEY,A7007)<br />BULB (6V,8W)
BULB(6V25/25W, STANLEY, A7007)
BULB (6V, 8W)

09471-06021-000   0947106021000

0947106021000

Unit Price

10
09471-12142
BULB (12V, 10W)

09471-12003-000  

0947112003000
Not available
11
BOLT

01107-06166-000  

01107-06163-000
 0110706166000

Unit Price

12
WASHER

08322-21066-000  

08322-0106A-000
 0832221066000

Unit Price

13
BRACKET, LICENSE PLATE

35927-09400-000   3592709400000

3592709400000
Not available
14
SCREW

02142-06125-000  

02142-0612B-000
 0214206125000

Unit Price

15
WASHER, LICENSE PLATE BRACKET

35926-09400-000   3592609400000

3592609400000
Not available
16
08310-0006A
.NUT 6MM

08310-12066-000  

0831012066000
Not available
17
CUSHION,LICENCE PLAT
CUSHION, LICENCE PLAT

09321-06013-000  

09321-06036-000
 0932106013000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TAIL LIGHT of your Suzuki of FB. Let us know if you have any questions.

Genuine parts for Suzuki 80 FB 1989
