FAIRING (MODEL M) REFER TO FIG.36A(G-11) FOR MODEL N

FAIRING (MODEL N) FOR SUZUKI DR 800 1991

FAIRING (MODEL P) REFER TO FIG.36C(G-13) FOR MODEL R/S/T

Item numbers

COVER, FRAME RH (BLUE)

47110-31D20-12F 4711031D2012F

Not available

COVER, FRAME RH (RED)

47110-31D20-1MW 4711031D201MW

Not available

COVER, FRAME RH (BLUE)

47110-31D50-12F 4711031D5012F

Not available

COVER, FRAME RH (RED)

47110-31D50-1MW 4711031D501MW

Not available

HEAT SHIELD

47166-31D00-000 4716631D00000

Not available

TAPE SET, RH

68130-31D10-1MT 6813031D101MT

Not available

TAPE SET, RH

68130-31D10-1MU 6813031D101MU

Not available

CUSHION

09320-09016-000 0932009016000

$3,97

Unit Price

COVER, FRAME LH (BLUE)

47210-31D20-12F 4721031D2012F

Not available

COVER, FRAME LH (RED)

47210-31D20-1MW 4721031D201MW

Not available

COVER, FRAME LH (BLUE)

47210-31D50-12F 4721031D5012F

Not available

COVER, FRAME LH (RED)

47210-31D50-1MW 4721031D501MW

Not available

TAPE SET, LH

68140-31D10-1MT 6814031D101MT

Not available

TAPE SET, LH

68140-31D10-1MU 6814031D101MU

Not available

CUSHION

09320-09016-000 0932009016000

$3,97

Unit Price

SCREW

09136-06081-000 0913606081000

$5,97

Unit Price

SPACER, 6.5X9X10

09180-06114-000

09180-06307-000

$5,97

Unit Price

FRAME COVER CUSHION

09320-08013-000

09320-08509-000

$4,97

Unit Price

CUSHION
CUSHION, CENTER

09320-08029-000 0932008029000

$3,97

Unit Price

SCREW

03242-05124-000

03241-0512A-000

$2,97

Unit Price

NUT, STEERING
NUT

09148-05038-000 0914805038000

$2,97

Unit Price

COVER, FRAME CENTER (BLUE)

47311-31D00-12F 4731131D0012F

Not available

COVER, FRAME CENTER (RED)

47311-31D00-1MW 4731131D001MW

Not available

BOLT

01517-06254-000

01550-0625B-000

$3,97

Unit Price

SPACER

09180-08147-000 0918008147000

Not available

CUSHION, PIPE COVER
CUSHION

09320-12031-000 0932012031000

$5,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FAIRING (MODEL N) of your Suzuki DR 800 S of DR. Let us know if you have any questions.
