FAIRING (MODEL N / P / R) REFER TO FIG.39A(F-13) FOR MODEL S/T/V

FAIRING (MODEL S / T / V) FOR SUZUKI INTRUDER 800 1992

HEADLAMP HOUSING

Item numbers

DISCONTINUE

47100-39A30-20F

Not available

DISCONTINUE

47100-39A30-33J

Not available

DISCONTINUE
EMBLEM

68131-39A10-C1L 6813139A10C1L

Not available

EMBLEM

68131-39A10-C1M 6813139A10C1M

Not available

COVER, FRAME RH (FREEN)

47110-38A00-1ZV 4711038A001ZV

Not available

DISCONTINUE

47110-38A00-20F

Not available

DISCONTINUE
EMBLEM

68131-39E00-000 6813139E00000

Not available

DISCONTINUE
COVER, FRAME RH (RED)

47110-38A00-19A 4711038A0019A

Not available

DISCONTINUE

47110-38A00-33J

Not available

DISCONTINUE
EMBLEM

68131-38E00-000 6813138E00000

Not available

COVER, FRAME LH (MAROON)

47200-39A30-20F 4720039A3020F

Not available

COVER, FRAME LH (BLACK)

47200-39A30-33J 4720039A3033J

Not available

DISCONTINUE
EMBLEM

68131-39A10-C1L 6813139A10C1L

Not available

EMBLEM

68131-39A10-C1M 6813139A10C1M

Not available

DISCONTINUE
COVER, FRAME LH (GREEN)

47210-38A00-1ZV 4721038A001ZV

Not available

COVER, FRAME LH (MAROON)

47210-38A00-20F 4721038A0020F

Not available

DISCONTINUE
EMBLEM

68131-39E00-000 6813139E00000

Not available

COVER, FRAME LH (RED)

47210-38A00-19A 4721038A0019A

Not available

DISCONTINUE
COVER, FRAME LH (BLAK)

47210-38A00-33J 4721038A0033J

Not available

DISCONTINUE
EMBLEM

68131-38E00-000 6813138E00000

Not available

BOLT
BOLT, RH

01550-06167-000 0155006167000

$3,97

Unit Price

WASHER(6.5X18X1.6)
WASHER

09160-06084-000 0916006084000

$2,97

Unit Price

SPACER(6.1X8X5.2)

09180-06032-000

09180-06246-000

$3,97

Unit Price

CUSHION(8X18X5.8)

09320-06017-000

09320-08516-000

$3,97

Unit Price

SCREW

02142-06103-000

02142-0610B-000

$2,97

Unit Price

FRAME COVER CUSHION

09320-08013-000

09320-08509-000

$4,97

Unit Price

BOSS, FRAME COVER

47250-38A01-000 4725038A01000

$14,97

Unit Price

MOLDING

47218-38A00-000

68241-04X50-300

$11,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
