FUEL TANK (MODEL K2 / K3) COLOR : CN5=YD8(SILVER),1LF(BLUE)

FAIRING FOR SUZUKI MARAUDER 800 2002

HEADLAMP HOUSING

Item numbers
FAIRING Suzuki MOTO 800 MARAUDER 2002 VZ800K2(E2)
1
1
1
2
2
2A
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
DISCONTINUE
COVER, FRAME RH

47111-48E00-000   4711148E00000

4711148E00000
Not available
1
DISCONTINUE

47111-48E40-000  

4711148E40000
Not available
2A
EMBLEM, FRAME COVER C

68271-34A00-20G  

68271-34A01-20G
 6827134A0020G

Unit Price

2
DISCONTINUE
COVER, FRAME LH

47211-48E00-000   4721148E00000

4721148E00000
Not available
2
DISCONTINUE
COVER, FRAME LH

47211-48E30-000   4721148E30000

4721148E30000
Not available
3
SCREW<br />SCREW (6X16)
SCREW
SCREW (6X16)

09139-06030-000   0913906030000

0913906030000

Unit Price

4
MUD GUARD WASHER<br />WASHER (6.5X18X1)
MUD GUARD WASHER
WASHER (6.5X18X1)

09160-06028-000   0916006028000

0916006028000

Unit Price

5
SPACER,6.5X10X7
SPACER, 6.5X10X7

09180-06263-000  

09180-06283-000
 0918006263000

Unit Price

6
CUSHION
CUSHION

09320-09016-000   0932009016000

0932009016000

Unit Price

7
CUSHION(8X26X7)
CUSHION(8X26X7)

09320-08018-000  

09320-08513-000
 0932008018000

Unit Price

8
COVER, FRAME HEAD, R
COVER, FRAME HEAD RH

47511-48E00-000   4751148E00000

4751148E00000

Unit Price

9
COVER, FRAME HEAD, L
COVER, FRAME HEAD LH

47521-48E00-000   4752148E00000

4752148E00000

Unit Price

10
SCREW<br />SCREW (6X16)
SCREW
SCREW (6X16)

09139-06039-000   0913906039000

0913906039000

Unit Price

11
CUSHION(8X26X7)
CUSHION(8X26X7)

09320-08018-000  

09320-08513-000
 0932008018000

Unit Price

12
DISCONTINUE
COVER, FRAME REAR RH

47120-48E00-000   4712048E00000

4712048E00000
Not available
13
DISCONTINUE
COVER, FRAME REAR LH

47220-48E00-000   4722048E00000

4722048E00000
Not available
14
BOLT<br />BOLT, FRONT
BOLT
BOLT, FRONT

09106-08140-000   0910608140000

0910608140000

Unit Price

15
DISCONTINUE
CUSHION, REAR

47129-48E00-000   4712948E00000

4712948E00000
Not available
16
COLLAR, 8.5X12X23.5
SPACER

09180-08197-000   0918008197000

0918008197000

Unit Price

17
BOLT

09106-08141-000  

09106-08156-000
 0910608141000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
