Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

LEVERS - HANDGRIPS

FRONT FORK (MODEL K / K2 / K3 / K4) FOR SUZUKI VOLUSIA 800 2003

FRONT FORK (MODEL K5)

Item numbers
FRONT FORK (MODEL K/K2/K3/K4) Suzuki MOTO 800 VOLUSIA 2003 VL800ZK3(E2)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
1
DISCONTINUE
DAMPER ASSY, FRONT FORK RH

51103-41F20-000   5110341F20000

5110341F20000
Not available
2
DISCONTINUE
DAMPER ASSY, FRONT FORK LH

51104-41F20-000   5110441F20000

5110441F20000
Not available
3
TUBE, OUTER, R
TUBE, OUTER RH

51131-41F20-000   5113141F20000

5113141F20000

Unit Price

4
TUBE, OUTER, L
TUBE, OUTER LH

51141-41F20-000   5114141F20000

5114141F20000

Unit Price

5
GUIDE, CASE

51469-41F21-000   5146941F21000

5146941F21000

Unit Price

6
BUSH, GUIDE

51152-11D60-000   5115211D60000

5115211D60000

Unit Price

7
SPACER, SEAL
SPACER, SEAL

51168-38B00-000   5116838B00000

5116838B00000

Unit Price

8
SEAL, OIL
SEAL, OIL

51153-08D00-000   5115308D00000

5115308D00000

Unit Price

9
CIRCLIP,FORK OIL SEAL<br />RING
CIRCLIP, FORK OIL SEAL
RING

51556-38B00-000   5155638B00000

5155638B00000

Unit Price

10
SEAL, DUST

51571-47D50-000   5157147D50000

5157147D50000

Unit Price

11
BOLT

51147-06F10-000   5114706F10000

5114706F10000

Unit Price

12
GASKET
GASKET

51148-36011-000   5114836011000

5114836011000

Unit Price

13
PIECE, OIL LOCK

51195-10F00-000   5119510F00000

5119510F00000

Unit Price

14
SEAT, PIPE
PIPE, SEAT

51146-10F00-000   5114610F00000

5114610F00000

Unit Price

15
SPRING, REBOUND
SPRING

51177-10F00-000   5117710F00000

5117710F00000

Unit Price

16
RING, PISTON
RING

51196-47D00-000   5119647D00000

5119647D00000

Unit Price

17
DISCONTINUE
TUBE, INNER

51110-41F20-000   5111041F20000

5111041F20000
Not available
18
BUSH, SLIDE

51121-42E00-000   5112142E00000

5112142E00000

Unit Price

19
DISCONTINUE
SPRING, FRONT

51171-41F20-000   5117141F20000

5117141F20000
Not available
20
DISCONTINUE
BOLT, INNER

51353-10F00-000   5135310F00000

5135310F00000
Not available
21
BOLT, FORK

51351-41F20-000   5135141F20000

5135141F20000

Unit Price

22
O RING

51117-38B00-000   5111738B00000

5111738B00000

Unit Price

23
BOLT<br />BOLT, LH
BOLT
BOLT, LH

07130-10357-000   0713010357000

0713010357000

Unit Price

24
CAP

09250-08014-000   0925008014000

0925008014000

Unit Price

25
CASE, UNDER

51464-41F21-000   5146441F21000

5146441F21000

Unit Price

26
SEAT, RUBBER

51468-10F00-000   5146810F00000

5146810F00000

Unit Price

27
WASHER

51467-10F00-000   5146710F00000

5146710F00000

Unit Price

28
SPACER

51465-41F20-000   5146541F20000

5146541F20000

Unit Price

29
BOLT

51466-10F00-000   5146610F00000

5146610F00000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
