TRANSMISSION

DRIVESHAFT FOR SUZUKI VX 800 1993

GEAR SHIFTING ASSY

DISCONTINUE
2ND.GEAR & HOUSING SET (NT:15)

24900-38822-000 2490038822000

Not available

BEARING (20X52X15)

09262-20073-000 0926220073000

$29,97

Unit Price

BEARING (20X34X16)

09263-20038-000 0926320038000

$64,97

Unit Price

STOPPER, SEC DRIVEN BEARING
STOPPER, BEARING

24942-38A50-000 2494238A50000

$60,97

Unit Price

HOUSING, OIL SEAL
HOUSING, OIL

24943-38A50-000 2494338A50000

$78,97

Unit Price

O RING (D:1.2, ID:59.6)

09280-60003-000 0928060003000

$3,97

Unit Price

OIL SEAL (38X54X8.5)

09283-38016-000 0928338016000

$25,97

Unit Price

GEAR, REDUCTION DRIVEN (NT:30)

24631-45C00-000 2463145C00000

Not available

BUSH, REDUCTION DRIVEN GEAR
BUSH

24632-38A00-000 2463238A00000

$18,97

Unit Price

DOG, OUTPUT CAM

24922-38A00-000 2492238A00000

$60,97

Unit Price

SPRING

09440-46003-000 0944046003000

Not available

CIRCLIP

08331-31216-000

08331-31219-000

$3,97

Unit Price

BOLT

07110-08256-000

07130-0825B-000

$5,97

Unit Price

SPR MOUNT DRUM NUT

09140-16014-000

09140-16005-000

$6,97

Unit Price

WASHER
WASHER (16X29X4)

09160-16029-000 0916016029000

$8,97

Unit Price

SHIM (T:0.30)

24935-38A01-030 2493538A01030

Not available

SHIM (T:0.35)

24935-38A01-035 2493538A01035

Not available

SHIM (T:0.40)

24935-38A01-040 2493538A01040

Not available

SHIM (T:0.50)

24935-38A01-050 2493538A01050

Not available

SHIM (T:0.60)

24935-38A01-060 2493538A01060

Not available

SHIM (T:0.30)

24945-05A00-0A0 2494505A000A0

Not available

SHIM (T:0.35)

24945-05A00-0B0 2494505A000B0

Not available

SHIM (T:0.40)

24945-05A00-0C0 2494505A000C0

Not available

SHIM (T:0.50)

24945-05A00-0D0 2494505A000D0

Not available

SHIM (T:0.60)

24945-05A00-0E0 2494505A000E0

Not available

O RING
O RING (D:2.1, ID:66.2)

09280-67004-000 0928067004000

$5,97

Unit Price

BOLT

07110-08256-000

07130-0825B-000

$5,97

Unit Price

PIN 7 X 12
PIN

04221-07129-000 0422107129000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the DRIVESHAFT of your Suzuki of VX. Let us know if you have any questions.
