FAIRING (MODEL T / V) COLOR : F3C = 1HU(PURPLE), 17U(GRAY)

FAIRING (MODEL W) FOR SUZUKI RF 900 1996

FRONT FENDER COLOR : D8A = Y22(PURPLE), 0FP(SILVER)

Item numbers

COVER, FRAME RH (MAROON)

47100-31E50-22U 4710031E5022U

Not available

COVER, FRAME RH (BLACK)

47100-31E50-33J 4710031E5033J

Not available

SHIELD, HEAT RH

47117-31E00-000 4711731E00000

Not available

TAPE SET, STRIPING RH

68130-31E00-F3H 6813031E00F3H

Not available

TAPE, RH

68135-31E00-G6M 6813531E00G6M

Not available

TAPE, RH

68135-31E00-G7U 6813531E00G7U

Not available

EMBLEM

68131-31E00-C9Y 6813131E00C9Y

Not available

EMBLEM

68131-31E00-J8N 6813131E00J8N

Not available

COVER, FRAME LH (MAROON)

47200-31E50-22U 4720031E5022U

Not available

COVER, FRAME LH (BLACK)

47200-31E50-33J 4720031E5033J

Not available

SHIELD, HEAT LH

47217-31E00-000 4721731E00000

Not available

DISCONTINUE
TAPE SET, STRIPING LH

68140-31E00-F3H 6814031E00F3H

Not available

TAPE, LH

68145-31E00-G6M 6814531E00G6M

Not available

TAPE, LH

68145-31E00-G7U 6814531E00G7U

Not available

EMBLEM

68131-31E00-C9Y 6813131E00C9Y

Not available

EMBLEM

68131-31E00-J8N 6813131E00J8N

Not available

SCREW

02142-05123-000

02142-0512A-000

$2,97

Unit Price

WASHER

09161-05017-000 0916105017000

$5,97

Unit Price

COVER, INNER RH

47511-31E00-000 4751131E00000

Not available

DISCONTINUE
COVER, INNER LH

47611-31E00-000 4761131E00000

Not available

SCREW, INNER COVER

03541-14123-000 0354114123000

Not available

DISCONTINUE
BRACKET, FRAME COVER RH

47191-21E00-000 4719121E00000

Not available

BRACKET, FRAME COVER LH

47192-21E00-000 4719221E00000

Not available

CUSHION(8X26X7)

09320-08018-000

09320-08513-000

$5,97

Unit Price

BOLT(6X25)
BOLT, FRONT

09116-06131-000 0911606131000

$3,97

Unit Price

CUSHION, FRAME COVER

47161-21E00-000

47161-21E01-000

$20,97

Unit Price

SPACER, 6.5X9X11
SPACER

09180-06265-000 0918006265000

$7,97

Unit Price

CUSHION

09320-08061-000 0932008061000

Not available

COVER, FRAME CENTER (GRAY)

47311-31E00-22U 4731131E0022U

Not available

DISCONTINUE
COVER, FRAME CENTER (BLACK)

47311-31E00-33J 4731131E0033J

Not available

DISCONTINUE
BRACKET, REAR

47193-21E00-000 4719321E00000

Not available

SCREW

02142-05123-000

02142-0512A-000

$2,97

Unit Price

NUT INST CENTER

09148-05021-000

09148-05013-000

$3,97

Unit Price

SCREW, REAR

03541-14123-000 0354114123000

Not available

SCREW

03241-15163-000

03241-1516A-000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FAIRING (MODEL W) of your Suzuki RF 900 of RF. Let us know if you have any questions.
