IGNITION (MODEL X) REFER TO FIG.14 (C- 8) FOR MODEL X E6,E24

IGNITION (MODEL X E6,E24) FOR SUZUKI AUTRES-MODELES 125 1999

IGNITION (MODEL W / K5)

Item numbers
IGNITION (MODEL X E6,E24) Suzuki MOTO 125 Autres-modeles 1999 TF125X(E1)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
STATOR ASSY

32101-48442-000   3210148442000

3210148442000
Not available
2
COIL, LIGHTING

32120-48442-000   3212048442000

3212048442000
Not available
3
SCREW

02112-04253-000  

02112-0425B-000
 0211204253000

Unit Price

4
WASHER, LOCK

08321-01043-000  

08321-0104A-000
 0832101043000

Unit Price

5
DISCONTINUE
COIL, PRIMARY

32140-39160-000   3214039160000

3214039160000
Not available
6
DISCONTINUE
COIL, PULSER

32150-40520-000   3215040520000

3215040520000
Not available
7
SCREW (4X30)

09125-04023-000   0912504023000

0912504023000

Unit Price

8
WASHER, LOCK

08321-01043-000  

08321-0104A-000
 0832101043000

Unit Price

9
FLYWHEEL

32102-48442-000   3210248442000

3210248442000
Not available
10
SCREW

02142-05123-000  

02142-0512A-000
 0214205123000

Unit Price

11
NUT

08316-10103-000  

08316-1010B-000
 0831610103000

Unit Price

12
WASHER<br />LOCK WASHER
WASHER
LOCK WASHER

08321-01107-000   0832101107000

0832101107000

Unit Price

13
WASHER
WASHER

08322-01107-000   0832201107000

0832201107000

Unit Price

14
KEY
KEY

08341-31039-000   0834131039000

0834131039000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the IGNITION (MODEL X E6,E24) of your Suzuki TF 125 of Autres-modeles. Let us know if you have any questions.

Genuine parts for Suzuki 125 Autres-modeles 1999
