Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

INDICATORS (MODEL X E6) REFER TO FIG.18 (D- 6) FOR MODEL X E24

INDICATORS (MODEL X E24) FOR SUZUKI AUTRES-MODELES 125 2005

INDICATORS (MODEL W / K5)

Item numbers
INDICATORS (MODEL X E24) Suzuki MOTO 125 Autres-modeles 2005 TF125K5(E1)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
LAMP, FRONT TURN SIGNAL

35601-41402-000   3560141402000

3560141402000
Not available
2
LENS

35612-10D00-000   3561210D00000

3561210D00000
Not available
3
BULB(6V25/25W,STANLEY,A7007)<br />BULB (6V,8W)
BULB(6V25/25W, STANLEY, A7007)
BULB (6V, 8W)

09471-06021-000   0947106021000

0947106021000

Unit Price

4
BRACKET, RH

35621-41400-000   3562141400000

3562141400000
Not available
5
BRACKET, LH

35641-41400-000   3564141400000

3564141400000
Not available
6
BOLT
BOLT

01500-10167-000   0150010167000

0150010167000

Unit Price

7
WASHER
WASHER

08322-01107-000   0832201107000

0832201107000

Unit Price

8
LAMP, REAR TURN SIGNAL

35603-29502-000   3560329502000

3560329502000
Not available
9
LENS

35612-10D00-000   3561210D00000

3561210D00000
Not available
10
BULB(6V25/25W,STANLEY,A7007)<br />BULB (6V,8W)
BULB(6V25/25W, STANLEY, A7007)
BULB (6V, 8W)

09471-06021-000   0947106021000

0947106021000

Unit Price

11
PILOT LAMP, TURN SIGNAL

36349-41400-000   3634941400000

3634941400000
Not available
12
BULB(6V8W, STANLEY, A4115)
BULB (6V, 3W)

09471-06002-000  

0947106002000
Not available
13
BRACKET

36347-41400-000   3634741400000

3634741400000
Not available
14
RELAY, TURN SIGNAL
RELAY, TURN SIGNAL

38610-06X50-000   3861006X50000

3861006X50000
Not available
15
BRACKET

38620-353A1-000   38620353A1000

38620353A1000
Not available
16
SCREW

02112-36123-000  

02112-3612A-000
 0211236123000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the INDICATORS (MODEL X E24) of your Suzuki TF 125 of Autres-modeles. Let us know if you have any questions.

Genuine parts for Suzuki 125 Autres-modeles 2005

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 125 Autres-modeles 2005

Select your Suzuki 2005 model

125 Autres-modeles 2005 TF125K5(E1)

TF 125

Suzuki Autres-modeles

Displacement: 125 cc
Year: 2005
Model code TF125K5(E1)
