FRONT FORK (MODEL X ~F.NO.126489) REFER TO FIG.38(G-4) FOR FRONT DAMPER MODEL X F.NO.126490%,MODEL W

FRONT FORK (SEE NOTE) FOR SUZUKI AUTRES-MODELES 125 2005

STEERING COLUMN (SEE NOTE) NOTE

Item numbers

DAMPER ASSY, FRONT FORK RH

51103-48440-000 5110348440000

Not available

DAMPER ASSY, FRONT FORK LH

51104-48440-000 5110448440000

Not available

TUBE, OUTER RH (BLACK)

51131-48200-291 5113148200291

Not available

TUBE, OUTER LH (BLACK)

51141-48200-291 5114148200291

Not available

SEAL, OIL
OIL SEAL

51153-48420-000 5115348420000

$18,97

Unit Price

SEAL, OIL STOPPER RING
RING, STOPPER

51156-48730-000 5115648730000

$6,97

Unit Price

PIECE, OIL LOCK

51195-48000-000 5119548000000

$17,97

Unit Price

BOLT(8X27)
BOLT

51147-48130-000 5114748130000

$6,97

Unit Price

GASKET

51148-36011-000 5114836011000

$5,97

Unit Price

HOLDER, AXLE (BLACK)

51132-48200-291 5113248200291

Not available

08322-0108A
WASHER

08322-01083-000

Not available

WASHER, LOCK

08321-01083-000

08321-0108B-000

$3,97

Unit Price

NUT

08310-00083-000

08310-0008B-000

$3,97

Unit Price

BOLT(6X8)
BOLT

09100-06011-000 0910006011000

$3,97

Unit Price

GASKET, DRAIN, PLUG
GASKET

51183-31030-000 5118331030000

$7,97

Unit Price

TUBE, INNER

51110-48000-000 5111048000000

Not available

CYLINDER

51146-48420-000 5114648420000

Not available

SPRING, REBOUND

51177-48000-000 5117748000000

Not available

RING
RING, PISTON

51196-48000-000 5119648000000

$10,97

Unit Price

SPRING, LOWER

51184-48420-000 5118448420000

Not available

SEAT, SPRING

51172-48000-000 5117248000000

Not available

SPRING, UPPER

51171-48420-000 5117148420000

Not available

O RING

51181-25030-000 5118125030000

$5,97

Unit Price

BOLT

51351-48000-000 5135148000000

$21,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRONT FORK (SEE NOTE) of your Suzuki TF 125 of Autres-modeles. Let us know if you have any questions.
