HEADLIGHT (E1) REFER TO FIG.21 (D-7) FOR E2,E4,E15,E18,E21

HEADLIGHT (E2,E4,E15,E18,E21) FOR SUZUKI DR 125 1987

HEADLIGHT (E24)

HEADLAMP ASSY

35100-13A22-999 3510013A22999

Not available

HEADLAMP ASSY

35100-13A52-999 3510013A52999

Not available

UNIT

35121-13A21-000 3512113A21000

Not available

UNIT

35121-13A51-000 3512113A51000

Not available

HOUSING

35141-14A00-000 3514114A00000

$55,97

Unit Price

SCREW

09125-05102-000

02112-05167-000

$2,97

Unit Price

WASHER(5.5X18X1)

35138-45230-000

09160-05045-000

$3,97

Unit Price

DISCONTINUE
SPACER

35133-14A00-000 3513314A00000

Not available

CUSHION

35139-45230-000 3513945230000

$2,97

Unit Price

NUT

35135-45900-000 3513545900000

$4,97

Unit Price

SCREW

35151-49200-000

35151-45900-000

$7,97

Unit Price

* 35154-31C00
SPRING

35154-49200-000 3515449200000

$9,97

Unit Price

SCREW , 4X50

35151-31300-000

09125-04020-000

$4,97

Unit Price

SPRING
SPRING, UPPER

35154-31300-000 3515431300000

$5,97

Unit Price

NUT

35135-45600-000 3513545600000

$5,97

Unit Price

HOLDER, BULB

35136-05300-000 3513605300000

Not available

COVER, SOCKET

35173-05300-000 3517305300000

Not available

SOCKET

36118-45900-000 3611845900000

Not available

BULB (12V, 45/40W)

09471-12048-000 0947112048000

Not available

BULB (12V, 45/40W)

09471-12049-000 0947112049000

Not available

BULB (12V, 4W)

09471-12063-000

Not available

BOLT

01107-06207-000

01500-06207-000

$3,97

Unit Price

WASHER 6.5X10X1.2

09160-06027-000

09160-06077-000

$2,97

Unit Price

SPACER, 6.5X10X7

09180-06011-000

09180-06283-000

$3,97

Unit Price

CUSHION

09320-09018-000 0932009018000

$2,97

Unit Price

PROTECTOR, WIRING HARNESS

36920-44A00-000

36920-14D00-000

$8,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the HEADLIGHT (E2,E4,E15,E18,E21) of your Suzuki DR 125 of DR. Let us know if you have any questions.
