GEAR SHIFTING ASSY

DRIVESHAFT FOR SUZUKI CAVALCADE 1400 1987

FUEL COCK

27311-24A03
.FINAL BEVEL GEAR SET

27300-24822-000

Not available

BEARING

09262-28009-000

09262-28023-000

$150,97

Unit Price

27312-24A02
.STOPPER, BEARING

27312-24A01-000

Not available

PLATE, STOPPER

27313-24A00-000 2731324A00000

Not available

PLATE, STOPPER

27313-24A10-000 2731324A10000

Not available

O RING
O RING (D:2.1, ID:66.2)

09280-67004-000 0928067004000

$5,97

Unit Price

WASHER(54X68X1.5)
WASHER

09160-54001-000 0916054001000

$14,97

Unit Price

SHIM (T:0.30)

27445-24A01-030 2744524A01030

Not available

SHIM (T:0.35)

27445-24A01-035 2744524A01035

Not available

SHIM (T:0.40)

27445-24A01-040 2744524A01040

Not available

SHIM (T:0.50)

27445-24A01-050 2744524A01050

Not available

SHIM (T:0.60)

27445-24A01-060 2744524A01060

Not available

OIL SEAL

09283-47001-000

09283-47002-000

$25,97

Unit Price

COUPLING, FINAL DRIVE GEAR

27172-24A00-000 2717224A00000

$59,97

Unit Price

WASHER

09160-16029-000 0916016029000

$8,97

Unit Price

NUT

09159-16003-000 0915916003000

$6,97

Unit Price

01421-1025B
STUD BOLT

01421-10258-000

Not available

BEARING

09263-20062-000 0926320062000

$54,97

Unit Price

FIN DRVN GR BEA *S1
BEARING, RH

09262-70001-000 0926270001000

$163,97

Unit Price

SHIM (T:0.35)

27327-45100-000 2732745100000

Not available

SHIM (T:0.40)

27327-45102-000 2732745102000

Not available

DISCONTINUE
SHIM (T:0.50)

27327-45103-000

Not available

.SHIM (T:0.60) BEARING

27327-45104-000 2732745104000

Not available

DRVN GEAR R OIL SEAL
OIL SEAL

09289-70001-000 0928970001000

$74,97

Unit Price

DRVN GEAR LH BEA****
BEARING, LH

09263-35004-000 0926335004000

$113,97

Unit Price

.SHIM (T:1.25) FI DR GEAR

27326-45100-000 2732645100000

Not available

SHIM (T:1.40)

27326-45100-140 2732645100140

Not available

SHIM (T:1.45)

27326-45100-145 2732645100145

Not available

SHIM (T:1.50)

27326-45100-150 2732645100150

Not available

SHIM (T:1.20)

27326-45101-000 2732645101000

Not available

.SHIM (T:1.05) FI DR GEAR

27326-45102-000 2732645102000

Not available

SHIM (T:1.10)

27326-45103-000 2732645103000

Not available

SHIM (T:1.35)

27326-45104-000 2732645104000

Not available

DISCONTINUE
HOLDER, BEARING

27329-45100-000 2732945100000

Not available

SCREW

02112-06128-000

02112-06127-000

$3,97

Unit Price

DRIVEN GEAR OIL SEAL
OIL SEAL (30X42X7)

09283-30028-000 0928330028000

$15,97

Unit Price

DISCONTINUE

27450-24A03-000

Not available

STUD BOLT

09108-10077-000 0910810077000

Not available

CASE, FINAL GEAR BEARING

27460-24A01-000 2746024A01000

Not available

O RING(D:1.9, ID:9.8)

09280-10010-000

09280-10016-000

$5,97

Unit Price

DISCONTINUE
BOLT

27481-24A00-000 2748124A00000

Not available

LOCK WASHER

09169-12003-000 0916912003000

Not available

NUT

08310-22127-000

09140-12039-000

$5,97

Unit Price

BOLT

01517-08307-000

01550-08307-000

$6,97

Unit Price

PLUG

09247-14012-000

09247-14026-000

$6,97

Unit Price

SPARK PLUG GASKET
GASKET

09168-14004-000 0916814004000

$2,97

Unit Price

PLUG, OIL DRAIN

09247-14019-000

09247-14036-000

$10,97

Unit Price

SPARK PLUG GASKET
GASKET

09168-14004-000 0916814004000

$2,97

Unit Price

SPRING

09440-30008-000 0944030008000

$4,97

Unit Price

DR CUP RING CIRCLIP
CIRCLIP

09381-40003-000 0938140003000

$7,97

Unit Price

PR CUP RING OIL SEAL
OIL SEAL (30X40.5X5.5)

09283-30026-000 0928330026000

$17,97

Unit Price

WASHER, LOCK

08321-31105-000

08321-01103-000

$3,97

Unit Price

FINAL GEAR CASE NUT

09159-10036-000

09159-10027-000

$5,97

Unit Price

DISCONTINUE

27100-24A05-000

Not available

COUPLING, PROPELLER SHAFT

27171-45101-000 2717145101000

Not available

DISCONTINUED

27300-24830-000 2730024830000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the DRIVESHAFT of your Suzuki CAVALCADE 1400 of CAVALCADE. Let us know if you have any questions.
