TAIL LIGHT (E22)

TAIL LIGHT (E39) FOR SUZUKI DR 250 1987

WIRING HARNESS

LAMP UNIT, REAR COMBUSTION

35720-38251-000 3572038251000

Not available

LAMP UNIT, REAR COMBUSTION

35720-38281-000 3572038281000

Not available

LAMP UNIT, REAR COMBUSTION

35720-38282-000 3572038282000

Not available

LENS

35712-38221-000 3571238221000

Not available

LENS

35712-38251-000 3571238251000

Not available

LENS

35712-38282-000 3571238282000

Not available

DISCONTINUE
GASKET

35713-38210-000 3571338210000

Not available

BULB (12V, 21W)

09471-12057-000 0947112057000

Not available

SCREW

03211-04308-000

03211-04306-000

$2,97

Unit Price

GASKET

35627-43010-000 3562743010000

$3,97

Unit Price

SCREW

02112-05165-000

02112-05164-000

$2,97

Unit Price

DISCONTINUED

35727-36510-000 3572736510000

Not available

WASHER, LOCK

08321-21057-000

08321-0105A-000

$2,97

Unit Price

NUT

08310-11058-000

08310-00057-000

$3,97

Unit Price

BRACKET UNIT

35730-38280-000 3573038280000

Not available

PLATE

35716-38210-000 3571638210000

Not available

CUSHION

35765-38210-000 3576538210000

Not available

CUSHION

35765-30950-000 3576530950000

Not available

SPACER

35766-38210-000 3576638210000

Not available

CUSHION

35717-38210-000 3571738210000

Not available

PLATE

35727-38280-000 3572738280000

Not available

BOLT

01107-06125-000

01500-0612A-000

$3,97

Unit Price

WASHER

08322-21064-000

08322-0106A-000

$3,97

Unit Price

SCREW

02142-06125-000

02142-0612B-000

$2,97

Unit Price

BOLT

01107-06306-000

01500-0630A-000

$3,97

Unit Price

08321-0106A
.WASHERLOCK6.1X12X1.2

08321-21066-000

Not available

DISCONTINUE
PLATE

35793-37201-000 3579337201000

Not available

BOLT

01107-06166-000

01107-06163-000

$3,97

Unit Price

CHAIN CASE WASHER

09169-06025-000

09169-06010-000

$4,97

Unit Price

NUT

08316-26066-000

08316-10067-000

$3,97

Unit Price

GROMMET

09308-09004-000 0930809004000

Not available

REFLECTOR, REFLEX FR
REFLEX REFLECTOR, REAR SIDE

35950-14A00-000 3595014A00000

$23,97

Unit Price

BRACKET, RH

35975-38200-000 3597538200000

Not available

BRACKET, LH

35976-38200-000 3597638200000

Not available

NUT

08316-16055-000 0831616055000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TAIL LIGHT (E39) of your Suzuki of DR. Let us know if you have any questions.
