Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

TRANSMISSION (1)

TRANSMISSION (2) FOR SUZUKI KINGQUAD 300 1993

DRIVESHAFT (MODEL M / N / P / R) REFER TO FIG.19A(D-10) FOR MODEL S

Item numbers
TRANSMISSION (2) Suzuki QUAD 300 KINGQUAD 1993 LT-F4WDXP(E3)
2
1
SHAFT, SUB T/M OUTPUT

29121-19B01-000  

29121-19B10-000
 2912119B01000

Unit Price

2
GEAR, SUB T/M DRIVEN NO.1
GEAR, DRIVEN NO.1 (NT:43)

29311-19B01-000   2931119B01000

2931119B01000

Unit Price

3
WASHER
WASHER, RH

08211-32441-000   0821132441000

0821132441000

Unit Price

4
WASHER, LOCK
WASHER, LH

09167-32002-000   0916732002000

0916732002000

Unit Price

5
GEAR, SUB T/M DRIVEN NO.2
GEAR, DRIVEN NO.2 (NT:37)

29320-19B00-000   2932019B00000

2932019B00000

Unit Price

6
DOG, SUB T/M DRIVEN SLIDING
DOG, DRIVEN GEAR

29331-19B00-000   2933119B00000

2933119B00000

Unit Price

7
WASHER THURST
WASHER

08211-25351-000   0821125351000

0821125351000

Unit Price

8
CIRCLIP

08331-31326-000  

08331-3132A-000
 0833131326000

Unit Price

9
BEARING(18X26X16)
BEARING, RH

09263-18023-000   0926318023000

0926318023000

Unit Price

10
BEARING(25X52X15)<br />BEARING, LH
BEARING(25X52X15)
BEARING, LH

09262-25003-000   0926225003000

0926225003000

Unit Price

11
BEARING 35X72X17
BEARING, MIDDLE (35X72X17)

09262-35038-000   0926235038000

0926235038000

Unit Price

12
RETAINER

24741-20A10-000  

24741-21A00-000
 2474120A10000

Unit Price

13
DISCONTINUE
RETAINER

24751-19B00-000   2475119B00000

2475119B00000
Not available
14
SCREW
SCREW

02112-06127-000   0211206127000

0211206127000

Unit Price

15
SCREW,6X16<br />SCREW
SCREW, 6X16
SCREW

02112-06167-000   0211206167000

0211206167000

Unit Price

16
GEAR SUB T/M DRIVE NO, 1

29211-19B00-000  

29211-19B01-000
 2921119B00000

Unit Price

17
BUSH, SUB T/M DRIVE NO.1 GEAR

29215-19B00-000  

29215-19B01-000
 2921519B00000

Unit Price

18
WASHER

09167-25016-000   0916725016000

0916725016000

Unit Price

19
GEAR, SUB T/M DRIVE NO.2
GEAR, DRIVE NO.2 (NT:25)

29220-19B00-000   2922019B00000

2922019B00000

Unit Price

20
DOG, SUB T/M DRIVEN SLIDING
DOG, DRIVE GEAR

29231-19B00-000   2923119B00000

2923119B00000

Unit Price

21
SHIM

08211-20301-000  

09181-20195-000
 0821120301000

Unit Price

22
SPACER (25X34X5.5)

09180-25083-000   0918025083000

0918025083000

Unit Price

23
3RD PINION CIRCLIP<br />CIRCLIP
3RD PINION CIRCLIP
CIRCLIP

09380-25003-000   0938025003000

0938025003000

Unit Price

24
GEAR, SUB T/M IDLE

29150-19B02-000  

29150-19B10-000
 2915019B02000

Unit Price

25
SPACER 17X24X4.5
WASHER (17X24X4.5)

09180-17076-000   0918017076000

0918017076000

Unit Price

26
WASHER

08211-15261-000  

09181-15195-000
 0821115261000

Unit Price

27
BEARING

09262-20069-000  

09262-20121-000
 0926220069000

Unit Price

28
BALL BEARING 15X42X1

09262-15022-000  

09262-15062-000
 0926215022000

Unit Price

29
FORK, SUB T/M GEAR SHIFT NO.1
FORK, NO.1

29511-19B00-000   2951119B00000

2951119B00000

Unit Price

30
FORK, SUB T/M GEAR SHIFT NO.2
FORK, NO.2

29521-19B00-000   2952119B00000

2952119B00000

Unit Price

31
SHAFT, GEAR SHIFT FORK NO.2

25421-35401-000  

25421-35402-000
 2542135401000

Unit Price

31
SHAFT, GEAR SHIFT FORK NO.2

25421-35403-000  

25421-35410-000
 2542135403000

Unit Price

32
SHAFT, GEAR SHIFT FORK

25411-09400-000  

25421-04702-000
 2541109400000

Unit Price

33
CAM, SUB T/M GEAR SHIFT
CAM, SUB TRANSMISSION GEAR

29610-19B10-000   2961019B10000

2961019B10000

Unit Price

34
STOPPER, SUB T/M SHIFT CAM
STOPPER

29630-19B00-000   2963019B00000

2963019B00000

Unit Price

35
SPRING

09443-09042-000   0944309042000

0944309042000

Unit Price

36
THRUST WASHER<br />WASHER
THRUST WASHER
WASHER

08211-06141-000   0821106141000

0821106141000

Unit Price

37
BOLT

09111-06019-000  

09111-06054-000
 0911106019000

Unit Price

38
RIVET<br />PIN
RIVET
PIN

09223-04001-000   0922304001000

0922304001000

Unit Price

39
ARM, T/M GEAR SHIFT
ARM

25360-19B70-000   2536019B70000

2536019B70000

Unit Price

40
BOLT
BOLT

01500-06207-000   0150006207000

0150006207000

Unit Price

41
WASHER

08322-11088-000  

08322-01087-000
 0832211088000

Unit Price

41
08322-0108A
WASHER

08322-01083-000  

0832201083000
Not available
42
E RING

08332-11063-000  

08332-1106B-000
 0833211063000

Unit Price

43
OIL SEAL<br />OIL SEAL (12X22X9)
OIL SEAL
OIL SEAL (12X22X9)

09285-12006-000   0928512006000

0928512006000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TRANSMISSION (2) of your Suzuki of KINGQUAD. Let us know if you have any questions.

Genuine parts for Suzuki 300 KINGQUAD 1993

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 300 KINGQUAD 1993

Select your Suzuki 1993 model

300 KINGQUAD 1993 LT-F4WDXP(E3)

Suzuki KINGQUAD

Displacement: 300 cc
Year: 1993
Model code LT-F4WDXP(E3)
4WD
